You can move the pattern for each channel, or for
two channels simultaneously depending on the
relative values from the current positions (see
page 163).
• 2801 to 2804, 2811 to 2814
You can set the vertical position as the brick slides
in.
• 2851 to 2854, 2861 to 2864
You can set the pattern position for each channel
setting when the first transition completes.
Pattern limit: You can restrict the range of the transition
execution as desired. However, this is not available for
an independent key DME wipe.
For details, see “Pattern Limit” (page 93).
Size: You can set the size of the image. This can only be
used when one of the following pattern numbers is
selected.
• 1201 to 1209, 1221 to 1225, 1251, 2651, 2652, 2851
to 2854, 2861 to 2864, 7201 to 7208, 7221 to 7224
Crop: You can crop the image. It is also possible in 16:9
mode to crop both sides and convert the image to a 4:3
aspect ratio.
For the execution of the transition, you can select from
the following three options.
•Cut
•Last 5%
• Linear
When [Last 5%] is selected, you can set the [Release
Transition] as follows.
• Last 30%
•Last 5%
•Off
When pattern numbers 1701, 1702, 2661, and 2662 are
selected, Crop cannot be used.
DME Wipe Restrictions
Relation to common wipes
• DME wipes do not use the wipe generator built into the
switcher. Therefore, during the execution of a DME
wipe, you can still use a pattern produced by the wipe
generator as the source for a pattern key or mask.
• A DME wipe pattern cannot be used as the source for a
pattern key or mask.
Relation to processed keys
• When using the DME for a processed key, selecting a
DME wipe automatically assigns an available DME for
use for DME wipes. If all DMEs are in use, then it is not
possible to select a DME wipe.
If a DME has been assigned in the Setup menu, that
setting takes precedence.
For details, see “Setting DME Channel Assignments”
(page 442).
• It is not possible to use a resizer DME wipe for a key
with processed key enabled.
Relation to image effect
It is not possible to use background DME wipes when an
image effect is set.
Relation to resizer
• When a resizer is enabled, it is not possible to select a
DME wipe or resizer DME wipe.
• For the key 1 and key 2, key 3 and key 4, key 5 and key
6, or key 7 and key 8 combinations, if one key is used for
a dual resizer effect, the other key cannot be used for a
DME wipe or resizer DME wipe.
Resizer DME wipe restrictions
When the screen aspect ratio is 4:3 in HD format, reducing
an image using the resizer reduces the 16:9 image as-is
with the added image portions on the left and right sides.
Use the crop function as required to extract the 4:3 image.
Number of DME wipes that can be used on a
single M/E bank
DME wipes can be used in nine places, including eight
independent key transitions.
When the switcher signal format is 3840×2160P 2SI, they
can be used in three places, including two independent key
transitions.
The number of keys to which DME effects (including
DME wipes) can be applied simultaneously for one M/E
bank varies as follows depending on the execution mode of
the DME wipe pattern selected for the background.
When the signal format is 3840×2160P 2SI, DME effects
(including DME wipes) can be used simultaneously in
only one place on an M/E bank. When not using
background DME wipes, DME effects can be used on
either key 1 or key 2.
Note
Note
Key to which
DME effects
are applied
DME wipe pattern
for background
Number of keys to
which DME effects
can be applied
simultaneously
Keys 1 to 4 DME wipes not used 2
1-channel mode 1
2-channel or
3-channel mode
0
Keys 5 to 8 – 2
