4K Format Restrictions
In 4K format, the following function and settings
restrictions apply.
Item Restrictions
Functions that
cannot be used in
the switcher
• M/E-5 bank (XVS-9000/8000),
M/E-3 to M/E-5 banks (XVS-7000),
M/E-2 to M/E-5 banks (XVS-6000)
a)
• Key 5 to key 8 (3840×2160P), key 3
to key 8 (3840×2160PsF)
• M/E Config multi-program 2 mode
• Utility 1 and 2 buses
• Side flags
• M/E split
• 3840×2160PsF SQD signal format
for the XKS-8215/XKS-7215 Mix
Effect Boards
DMEs • In SQD, DMEs not supported
• On the XVS-8000/7000, channels 3
and 4 not supported (DME utility 1
bus and 2 bus not supported)
• On the XVS-6000, channels 2 to 4
not supported (DME external video
bus, DME utility 1 bus and 2 bus not
supported)
• On the XVS-8000, DME MON K
output not supported
• Ext In input signals not supported
Screen aspect Fixed to 16:9
Transitions • [FM5&6 Clip] and [FM7&8 Clip] clip
transitions not supported
• Preset color mix using Utility 2 bus
not supported
• When key 1 (key 2) is selected for
the next transition and DME wipe is
selected as the transition type, key 1
(key 2) independent key transition
wipes not supported
Keys • Key 3 and key 4 function as sub keys
for the XKS-8210/XKS-7210 Mix
Effect Boards
• Wipe pattern keys not supported
• [Filter] parameter settings for
luminance keys, linear keys, and
chroma keys not supported
• [Y Filter] and [C Filter] parameters
for color vector keys not supported
• [Key Position] settings for luminance
keys, linear keys, color vector keys,
and chroma keys not supported
• [Filter] parameter settings for color
cancel key of chroma keys not
supported
• [Key Position] settings for color
cancel key of chroma keys not
supported
• [Shadow] settings for chroma keys
not supported
• In SQD, auto chroma key sample
mark for a region spanning two or
more sub images (image subdivided
by 4) not supported
• In SQD, [Multi] settings for key wipe
pattern key not supported
• [Edge Blink] blinking not supported
• Submask settings not supported
• In SQD, edge settings not supported
• In 2SI, [Utility 1 Bus] in <Edge Fill>
group not supported
• In SQD, [Multi] settings for main
masks not supported
• PROC V and PROC K signals not
supported
Resizer • In 3840×2160PsF, resizer not
supported
• Dual resizer effects not supported
Wipes • In SQD, standard and enhanced
group patterns only supported
• In SQD, pattern mix not supported
• In SQD, [Multi] and [Pairing] not
supported
• In SQD, only single color edge
border and soft border supported
DME wipes • In 3840×2160PsF, DME wipes not
supported
• In 3840×2160P SQD, only resizer
DME wipes supported
• Background images use flat color or
mix color signals
Frame memory • FM5 to FM20 not supported
• Frame memory feed not supported
Safe titles • Outputs with active area of
4096×2160 not supported
• In SQD, [Grid] not supported
Item Restrictions
