19
NW-E103/E105/E107
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN400 1-818-513-21 CONNECTOR (SQUARE TYPE) (USB) 5P ( )
CN850 1-817-288-41 CONNECTOR, FFC/FPC (ZIF) 8P
< DIODE >
D300 8-719-056-59 DIODE MAZS120008SO
D501 6-500-460-01 DIODE RSX101M-30TR
D502 8-719-069-28 DIODE 1SS400TE-61
D503 8-719-069-28 DIODE 1SS400TE-61
D504 6-500-460-01 DIODE RSX101M-30TR
D703 8-719-069-29 DIODE RB520S-30TE61
D801 8-719-052-12 DIODE 1SS403 (TPH3)
< FERRITE BEAD >
FB100 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB200 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
FB300 1-543-958-22 BEAD, FERRITE (CHIP) (1608)
FB302 1-469-082-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC301 6-703-295-01 IC NJM2776RB2 (TE2)
IC400 8-753-234-35 IC CXR704060-202GA
★ IC450 ––––––––––– IC S99-50082 (E107)
★ IC450 ––––––––––– IC S29AL016D70BFI020 (E103/E105)
IC461 6-707-829-01 IC K04SONY99 (E107)
IC461 6-707-830-01 IC K04SONY95 (E105)
IC461 6-708-162-01 IC K05SONY03 (E103)
IC500 6-706-898-01 IC S-80809CNPF-B9N-TF
IC501 6-706-899-01 IC S-80810CNPF-B9O-TF
IC502 6-706-899-01 IC S-80810CNPF-B9O-TF
IC503 6-701-734-01 IC XC9105D091MR
IC504 6-703-317-01 IC R1160N121B-TR-FA
IC505 6-706-900-01 IC S-80824CNPF-B8J-TF
IC506 8-759-657-74 IC XC62HR3302MR
IC507 6-701-734-01 IC XC9105D091MR
IC508 6-703-298-01 IC XC62HR2802MR
IC509 6-704-021-01 IC XC62HR2301MR
IC510 6-706-900-01 IC S-80824CNPF-B8J-TF
IC700 8-759-641-91 IC RV5C348A-E2
IC801 8-759-830-70 IC SM8142BD-G-EL
< JACK >
J301 1-817-124-11 JACK (i)
< COIL >
L500 1-419-861-21 INDUCTOR 100uH
L501 1-419-861-21 INDUCTOR 100uH
L801 1-414-406-41 INDUCTOR 220uH
< TRANSISTOR >
Q451 8-729-056-42 TRANSISTOR 2SC5658T2L
Q452 6-550-132-01 TRANSISTOR 2SA2029T2L
Q460 8-729-041-23 TRANSISTOR NDS356AP
Q461 6-551-346-01 TRANSISTOR 2SK3541T2L
Q500 8-729-053-03 TRANSISTOR XP151A12A2MR
Q501 6-550-746-01 TRANSISTOR 3LN01S-K-TL-E
Q502 8-729-056-42 TRANSISTOR 2SC5658T2L
Q503 8-729-427-74 TRANSISTOR XP4601-TXE
Q504 6-550-132-01 TRANSISTOR 2SA2029T2L
Q505 8-729-052-37 TRANSISTOR XP151A13A0MR
Q506 8-729-056-42 TRANSISTOR 2SC5658T2L
Q507 6-550-132-01 TRANSISTOR 2SA2029T2L
< RESISTOR >
R100 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R101 1-218-929-11 RES-CHIP 10 5% 1/16W
R102 1-218-971-11 RES-CHIP 33K 5% 1/16W
R103 1-218-973-11 RES-CHIP 47K 5% 1/16W
R200 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R201 1-218-929-11 RES-CHIP 10 5% 1/16W
R202 1-218-971-11 RES-CHIP 33K 5% 1/16W
R203 1-218-973-11 RES-CHIP 47K 5% 1/16W
R300 1-218-990-11 SHORT CHIP 0
R302 1-218-973-11 RES-CHIP 47K 5% 1/16W
R303 1-218-990-11 SHORT CHIP 0
R400 1-218-989-11 RES-CHIP 1M 5% 1/16W
R401 1-218-965-11 RES-CHIP 10K 5% 1/16W
R402 1-218-965-11 RES-CHIP 10K 5% 1/16W
R403 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R404 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R405 1-218-990-11 SHORT CHIP 0
R406 1-218-933-11 RES-CHIP 22 5% 1/16W
R407 1-218-933-11 RES-CHIP 22 5% 1/16W
R408 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R409 1-218-933-11 RES-CHIP 22 5% 1/16W
R410 1-218-941-81 RES-CHIP 100 5% 1/16W
R411 1-218-989-11 RES-CHIP 1M 5% 1/16W
R412 1-218-945-11 RES-CHIP 220 5% 1/16W
R414 1-218-990-11 SHORT CHIP 0 (E103/E105)
R415 1-218-977-11 RES-CHIP 100K 5% 1/16W
R416 1-218-965-11 RES-CHIP 10K 5% 1/16W
R420 1-218-965-11 RES-CHIP 10K 5% 1/16W
R421 1-218-977-11 RES-CHIP 100K 5% 1/16W
R422 1-218-965-11 RES-CHIP 10K 5% 1/16W
✩ R423 1-218-990-11 SHORT CHIP 0 (LCD Part No. SUFFIX-21)
R424 1-218-990-11 SHORT CHIP 0 (E107)
✩ R425 1-218-990-11 SHORT CHIP 0 (LCD Part No. SUFFIX-11)
R431 1-218-990-11 SHORT CHIP 0
R432 1-218-990-11 SHORT CHIP 0 (E107)
R433 1-218-990-11 SHORT CHIP 0
R450 1-218-990-11 SHORT CHIP 0
R451 1-218-977-11 RES-CHIP 100K 5% 1/16W
R452 1-218-977-11 RES-CHIP 100K 5% 1/16W
R453 1-218-985-11 RES-CHIP 470K 5% 1/16W
R454 1-218-985-11 RES-CHIP 470K 5% 1/16W
R455 1-218-977-11 RES-CHIP 100K 5% 1/16W
(E103/E105)
R457 1-218-989-11 RES-CHIP 1M 5% 1/16W
R458 1-218-985-11 RES-CHIP 470K 5% 1/16W
R459 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R460 1-218-989-11 RES-CHIP 1M 5% 1/16W
R461 1-218-977-11 RES-CHIP 100K 5% 1/16W
R462 1-218-990-11 SHORT CHIP 0
R463 1-218-977-11 RES-CHIP 100K 5% 1/16W
R464 1-218-990-11 SHORT CHIP 0 (E103/E105)
R465 1-218-990-11 SHORT CHIP 0 (E107)
MAIN
✩ Refer to NOTE WHEN REPLACING THE LCD (Page 22)
about R423 and R425 usage.
Ver. 1.4
★ IC450 cannot be replaced individually.
Replace it with MAIN board assembly for service.
To Next Page
