NW-E103/E105/E107
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Accessories are given in the last of this parts
list.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
R R
Parts of Color Cabinet’s Color
When indicating parts by reference number,
please include the board name.
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
AUS: Australian model
CND : Canadian model
HK : HongKong model
JE : Tourist model
KR : Korean model
MAIN
Ver. 1.4
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
X-2059-678-1 MAIN BOARD, COMPLETE (E103 : AEP)
X-2059-679-1 MAIN BOARD, COMPLETE (E103 : EXCEPT AEP)
X-2059-681-1 MAIN BOARD, COMPLETE (E105 : AEP)
X-2059-682-1 MAIN BOARD, COMPLETE (E105 : EXCEPT AEP)
X-2059-684-1 MAIN BOARD, COMPLETE (E107 : AEP)
X-2059-685-1 MAIN BOARD, COMPLETE (E107 : EXCEPT AEP)
*********************
✩ 1-805-848-11 DISPLAY PANEL, LIQUID CRYSTAL
✩ 1-805-848-21 DISPLAY PANEL, LIQUID CRYSTAL
1-805-850-11 ELEMENT, EL
2-320-677-01 CUSHION (LCD)
2-589-665-01 HOLDER, LCD
2-589-666-01 TERMINAL (+), BATTERY
2-589-667-01 TERMINAL (–), BATTERY
2-597-673-01 SHEET (EL), ADHESIVE
2-597-707-01 SHEET (NAND), INSULATING
2-597-708-01 SHEET (CONNECTOR), INSULATING
< CAPACITOR >
C100 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C101 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C102 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C103 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C104 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C200 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C201 1-135-868-91 TANTAL. CHIP 220uF 20% 2.5V
C202 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C203 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C204 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C300 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C303 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C304 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C305 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C400 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C401 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-131-860-91 TANTAL. CHIP 4.7uF 20% 10V
C403 1-131-860-91 TANTAL. CHIP 4.7uF 20% 10V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C408 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C411 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C414 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C415 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C416 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C417 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C418 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C419 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C421 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C450 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C451 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C452 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C462 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C464 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C500 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
C501 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C503 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C504 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
C505 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C506 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C509 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C510 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C511 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C512 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C513 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C515 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C517 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
C518 1-164-862-11 CERAMIC CHIP 33PF 5% 50V
C519 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C521 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C522 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C700 1-756-305-11 BATTERY, PAS SECONDARY
C701 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C702 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C703 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C704 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C705 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C706 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C707 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C709 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C801 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C802 1-100-437-91 CERAMIC CHIP 4700PF 5% 100V
C860 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C867 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
✩ When replacing the LIQUID CRYSTAL DISPLAY PANEL,
refer to NOTE WHEN REPLACING THE LCD (Page 22).
To Next Page
