– 10 –
2-4. MAIN BOARD
2-5. CD BOARD
2
BVTP 3x10
1
CNP304
3
MAIN board
1
CNP701
2
CNP703
3
connector
5
BVTP 3x10
6
CD board
4
BVTP 3x10
