– 9 –
2-2. CD CHASSIS ASSY
2-3. POWER BOARD
2
BVTP 3x10
3
wire
5
CD chassis assy
1
BVTP 3x1
0
4
CNP901
2
BVTP 4x16
3
POWER board
1
CNP902
