– 8 –
SECTION 2
DISASSEMBL
Y
3
BVTP 3x14
1
BVTP 3x14
2
BVTP 3x1
4
4
CNP303
5
CNP301
9
CNP702
6
CNP302
7
CNP306
8
CNP308
0
front cabinet assy
•
The equipment can be removed using the following procedure.
Set
Front cabinet assy
CD chassis assy
Main board
Power board
CD board
Optical pick-up
Mechanism deck block
Control board
Note :
Follow the disassembly procedure in the numerical order given.
2-1.
FR
ONT CABINET ASSY
7
9
