1-1. FEATURES
This chart shows the various features which your model has (indicated as "Yes").
Features
PVM-1343MD
PVM-13420
Automatic whtte balance circuit Yes
Yes
SMPTE-C phosphor
Yes
Yes
Black-tinted Trinitron tube
No
No
Super Fine Pitch Trinitron picture tube Yes
Yes
Analog RGB input/output Yes
Yes
Y/C input (4-pin DIN)
Yes
Yes
VTR input (6-pin)
Yes
Yes
Control S inpuVoutput
Yes
Yes
Automatic termination of BNC-type input connectors
Yes
Yes
Color systems available PAL, SECAM, NTSC3.58 NTSC4.43
Colorpure filter
Yes
Yes
Blue only mode
Yes
Yes
Underscan mode Yes
Yes
Horizontal/vertical delay mode
Yes
Yes
External sync input Yes Yes
Color temperature selector
Yes Yes
Light-touch picture adjustment buttons
Yes
Yes
EIA standard 19-inch rack mounting
Yes
Yes
Digital RGB input (9-pin)
Yes
Yes
PVM-1341
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Yes
NTSC3.58 only
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
SECTION 1
GENERAL·
Automatic while balance circuit
The automatic white balance circuit compensates for the
beam distortion, secular distortion of lhe cathode.ray tube,
etc., and always reproduces the same white display on the
screen. This allows an extended use of the monitvi.
Super Fine Pilch Trinitron picutre tube
(PVM·1344Q/PVM-1343MD/PVM·1342Q only)
The Super Fine Pitch Trinitron picture tube (0.25 mm aperture
grill) gives high resolution picture. Horizontal resolution is
more than 6(X) TV lines at the center of the picture. When
used as a character display, up to 2,000 characters (80
characters/line x 25 lines} can be displayed with great clarity.
Analog RGB connector
Analog RGl3 signal of a video equipment can be input
through this connector.
Y/C Input connector
The video signal split into the chrominance signal (C) and the
luminance signal (Y) can be input through this connector,
eliminating the interference between the two signals which
tends to occur in a composite video signal and assuring the
video quality.
VTR Input connector
When connected to a VCR having the 8-pin TV connector,
video and audio signals can be fed through this connector
with a single cable.
Control S connector
When this connector is connected to the "control S" output
of other equipment, the remote controls of the aperture,
brightness, chroma, phase, contrast and volume settings are
possible.
Automatic tenminalion of BNC-type input connector
The BNC-type input connector is terminated at 75 ohms
inside, when no cable is connected to the output connector.
When lhe cable is connected to lhe output connector, the
75-ohms termination is automatically released, and the
signal input to the corresponding IN connector is output
from the output connector.
Four color systems available
(PVM-1343MD/PVM-1342Q only)
The monitor can display PAL, SECAM, NTSC3.58 and
NTSCt43• signals. The appropriate color system is selected
automatically.
• A signal of NTSC4.43 ls obtained by playing back NTSC-
recorded video cassettes with a video tape recorder/player
especially designed for use wilh this system.
"
Colorpure Filter
When NTSC video signals are received, a colorpure filter
aclivates to increase the resolution about 35%, resulting in
fine picture detail without color spill or color noise.
Blue only mode
In the bjue only mode, an apparent monochrome display is
oblained with all three cathodes driven with a blue signal.
This facilitates color saturation and phase adjustments and
observation of VCR noise.
Underscan mode
The signal normally Scanned outside of the screen can be
monitored in the underscan mode.
Horizontal/vertical delay mode
The horizontal and vertical sync signals can be checked
simultaneously in the HN delay mode.
External sync Input
When the EXT SYNC (or ANALOG/DIGIT AL (EXT SYNC))
bullon is depressed, the monitor can be operated on the
sync signal supplied from an external sync generator.
Color temperature selector
Color temperature of either 9,300°K or 6,500°K Is selectable
wilh the COLOR TEMP selector. For precise adjustment, use
the BIAS and GAIN adjustment controls (except PVM-1340).
Light-touch picture adjustment buttons
The aperture, brightness, chroma, phase, contrast and
volume buttons can be adjusted by touching the buttons
lightly. The adjusted settings will be stored in memory even
when the monitor is turned off.
EIA standard 19-inch rack mounting
By using an optional MB·502A mounting bracket, the monitor
can be mounted in an EIA standard 19-inch rack. An optional
SLR·102 slide rail is also available. For details on mounting,
see the appropriale. instruction manual.
