Switching the Input Signal / Protection of the Setting Values
Switching the Input Signal
The ASSIGN 1/2 buttons on the side panel of this unit or
the numeric buttons of the optional Sony Monitor
Control Unit BKM-16R can switch input signals that are
compatible to each input connector of this unit (SDI1
4K, SDI1 2K, SDI2 4K, SDI2 2K, or HDMI).
The following operations are available in the factory
default settings of each button.
To switch by using the ASSIGN 1 button of
this unit
1 Press the ASSIGN 1 button.
[Input Select/Input Setting] menu is displayed.
2 Select [Input Select].
3 Select the input signal to the monitor from [SDI1
4K], [SDI1 2K], [SDI2 4K], [SDI2 2K], or [HDMI].
To switch by using the numeric buttons of
BKM-16R
Each input signal compatible to this unit is assigned to
the 1 to 5 buttons. Switch the input signal to the monitor
by pressing a button.
1 button: [SDI1 4K]
2 button: [SDI1 2K]
3 button: [SDI2 4K]
4 button: [SDI2 2K]
5 button: [HDMI]
Note
Check the settings of each button in the following menu
if the factory default settings are changed.
 ASSIGN 1/2 buttons of this unit: [Assign Button
Setting] (page 33)
 Numeric buttons of BKM-16R: [Function/Numeric
Button Setting] (page 38)
Protection of the Setting
Values
You can protect the setting values of the color
temperature for [User1] and the User Preset for [User
Preset1] using [Password Lock].
When the values are protected with a password, you
need to enter the password during the following
operations.
 When you change the color temperature values for
[User1] using [Adjust Gain/Bias] or [Copy From].
 When you change the User Preset values for [User
Preset1].
For details, see [Password Lock] (page 39).
