Specifications
DECK A (the CD player section)
System Compact disc and digital
audio system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Frequency response 20 Hz – 20,000 Hz (±0.5
dB)
Signal-to-noise ratio More than 100 dB
Dynamic range More than 93 dB
DECK B (the CD-R and CD-RW
recording section)
System Compact disc digital audio
system
Laser Semiconductor laser (λ =
780 nm)
Emission duration:
continuous
Playable discs CD, CD-R, CD-RW
Recordable discs CD-R, CD-RW (for music
use)
Frequency response 20 to 20,000 Hz ±0.5 dB
Signal-to-noise ratio Over 96 dB during
playback
Dynamic range More than 93 dB during
playback
Inputs
ANALOG IN
(Phono jacks) impedance 47 kilohms
Rated input 330 mVrms
Minimum input
125 mVrms
DIGITAL OPTICAL IN
(Square optical connector jack)
Optical wavelength
660 nm
Outputs
ANALOG OUT
(Phono jacks) impedance 47 kilohms
Rated output 2 Vrms
Load impedance over
10 kilohms
OPTICAL DIGITAL OUT
(Square optical connector jack)
Wavelength 660 nm
Output level -18 dBm
General
Power requirements
U.S.A. and Canada 120 V AC, 60 Hz
Power consumption 28 W
Dimensions (approx.) (w/h/d) incl. projecting parts
and control
430 × 108 × 368 mm
Mass (approx.) 4.6 kg
Supplied accessories
See page 5.
Design and specifications are subject to change
without notice.
