Sony RDR-GX257 Servise Manual

2-3E
RDR-GX257/GX380
2-5. IO BOARD
2-6. CIRCUIT BOARDS LOCATION
3 Flexible flat cable (MI-1)
6 IO board
1 Harness
2 Flexible flat cable (MI-2)
4 Five screws
5 Four screws
KEY board
MAIN board
TIMER board
IO board
HDMI board
