Sony RM-B150 - Basic Menu; Detail Menu

10 (E)
Basic Menu
(A boxed item under “Setting” indicates the factory setting.)
Category Subcategory Item Setting Contents
Cbl Comp – Len [10m], 50m, 100m Sets the cable length for the cable compensation circuit.
Bright
–
LED 10 to 99 ([50]) Sets the brightness of the LEDs on the control panel.
Disp 10 to 99 ([50]) Sets the brightness of the menu display.
Buzzer
–
Lvl 0 to 99 ([50]) Sets the sound volume of the buzzer.
Out [On], Off Turns buzzer output on and off.
Detail Menu
(A boxed item under “Setting” indicates the factory setting.)
Category Subcategory Item Setting Contents
Mode Set – Act Md2, [Md3] Selects the control mode.
Md2: Each time the ACTIVE button is pressed, FULL and
LOCK are toggled.
Md3: Each time the ACTIVE button is pressed, FULL,
PART and LOCK are cyclically switched.
FltMax 4, [5] Sets the default nambers of the ND and CC filters.
However, when the connected camera has an automatic
filter detection facility, setting this item is not required.
Gain SW – L (RM) –3, [0], 3, 6, 9, 12, 15, Selects the gain value for GAIN selector position LOW in
18, . . . , 42 Gain Local mode (in 3 dB steps to 42 dB max.)
1)
.
M (RM) –3, 0, 3, 6, [9], 12, 15, Selects the gain value for GAIN selector position MID in
18, . . . , 42 Gain Local mode (in 3 dB steps to 42 dB max.)
1)
.
H (RM) –3, 0, 3, 6, 9, 12, 15, Selects the gain value for GAIN selector position HIGH in
[18], . . . , 42 Gain Local mode (in 3 dB steps to 42 dB max.)
1)
.
Mode RM, [CAM] Selects the Gain Local/Remote mode.
RM: Gain Local mode (The gain is controlled according to
the settings on this unit regardless of the GAIN L/M/H
settings on the camera.)
CAM: Gain Remote mode (The gain is controlled according
to the GAIN L/M/H settings on the camera. Effective only
with a camera equipped with an automatic detection
facility.)
SW Setup – AtKnee [AtKnee], KneeSat, Selects the function of the AUTO KNEE button.
BlkGamma, SkinDtl AtKnee: Turns the Auto knee function on and off (on when
lit).
KneeSat: Turns the Knee saturation function on and off (on
when lit).
BlkGamma: Turns the Black gamma function on and off (on
when lit).
SkinDtl: Turns the Skin detail function on and off (on when
lit).
Test [1], 2, 3 Selects the output signal when the OUTPUT selector is set
to the TEST position.
1: Gamma-waveform signal
2: Three-value staircase signal
3: Ten-value staircase signal
Settings on the RM Configuration Menu
1) Which value may be selected depends on the camera being used.
