42
Settings on the RM Configuration Menu
a)
·
Once you have assigned a function to the assignable 1 or 2 button, label the button with the supplied
function label to prevent erroneous operation.
·
Before changing a function to be assigned to the assignable 1 or 2 button, check if the status of the
currently assigned function on the camera (ON/OFF status and adjustment value) is identical to what
you intended. This is why the status of that function may not be controlled from both the Remote
Control Unit and the camera after its assignment has been released.
b) To perform this function, press and hold the assignable 1 button for one second or more.
ASSIGN-
ABLE 2
a)
A2
0 - 9
Assigns a function to the assignable 2
button.
0: NO ASSIGN (no function assigned)
1: MW GAIN (adjusting the master
white gain)
2: KNEE (turning ON/OFF and
performing the master knee point
adjustment)
3: M GAMMA (turning ON/OFF and
performing the master gamma
adjustment)
4: BLACK GAMMA (adjusting the
master black gamma)
5: MASTER FLARE (turning ON/OFF
and performing the master flare
adjustment)
6: SATURATION (turning ON/OFF and
performing the saturation
adjustment)
7: S&Q (turning ON/OFF the slow &
quick motion function and selecting a
recording frame rate for slow & quick
motion recording)
8: ZOOM (selecting remote/local mode
and performing focal distance
adjustment)
9: FOCUS (selecting remote/local
mode and performing focus
adjustment)
Item Item
indication
(on MASTER
GAIN
indicator)
Setting
(on adjustment
value
indicator)
Function
