KV-24FV10/25FV10/25FV10C
63 HSS H SYNC SLICE LEVEL 0, 1 0 0
64 HMSK 0, 1 0 0
65 VTMS SELECT SIGNAL VTIM PIN 0-3 0 0
66 CDMD V CNT DWN MODE SWITCHING 0-3 0 3 0
67 AFC AFC LOOP GAIN SWITCHING 0-3 0 0 0
68 FIFR FIELD FREQUENCY 0-3 3 1 3
69 SBAL SUB BALANCE 0-15 7 7
70 SBAS SUB BASS 0-15 9 9
71 STRE SUB TREBLE 0-15 9 9
72 BBEL BBE LOW 0-15 12 12
73 BBEH BBE HIGH 0-15 9 9
74 SRND SURROUND 0-63 13 13
75 BBE BBE ON/OFF 0, 1 1 1
76 DISP O.S.D DISPLAY POSITION 0-63 22 15
77 TROT TILT CORRECTION 0-63 31 31
78 HCLW HORIZONTAL COUNT LOWER LIMIT 0-127 16 16 16
79 HCHG HORIZONTAL COUNT HIGH LIMIT 0-127 64 64 64
80 ABL0 0, 1 0 1
81 ABL1 0-7 0 7
82 SYSC COLOR SYSTEM 0-7 6 6
83 VENH VERTICAL ENHANCEMENT 0-7 Palette mode controls this register 4
84 CBPC 0, 1 0 0
85 BYCF 0, 1 0 0
86 KILC 0, 1 0 0
87 LDOT 0, 1 0 0
88 CORE 0, 1 0 0
89 ID0 0-255 201 See ID Map
90 ID1 0-255 19 See ID Map
91 ID2 0-255 173 See ID Map
92 ID3 0-255 43 See ID Map
93 ID4 0-255 251 See ID Map
94 ID5 0-255 0 See ID Map
95 ID6 0-255 64 See ID Map
NO. ITEM FUNCTION
DATA
RANGE
INITIAL DATA
AVERAGE
DATANTSC
PALM/
PALN VIDEO
SERVICE ID0 25
Notes:
No. 1–95 show the order that each adjustment mode may be selected while in service mode.
Data Range shows the range of possible settings for each adjustment mode.
Initial Data shows the standard settings for each adjustment mode.
