— 23 —
KV-24FV10/25FV10/25FV10C
Adjustment Items
NO. ITEM FUNCTION
DATA
RANGE
INITIAL DATA
AVERAGE
DATANTSC
PALM/
PALN VIDEO
1 HSIZ HORIZONTAL SIZE ADJ. 0-63 35 35 38
2 HPOS HORIZONTAL POS. ADJ. 0-63 33 33 21
3 VBOW VRT LINE BOWING ADJ. 0-15 5 5 9
4 VANG VRT LINE BOW SLANT ADJ. 0-15 7 7 5
5 TRAP HORIZ. TRAPEZOID ADJ. 0-15 7 7 7
6 PAMP HORIZ. PIN DISTORTION ADJ. 0-63 7 7 32
7 UPIN UPPER PIN DISTORTION ADJ. 0-63 36 36 39
8 LPIN LOWER PIN DISTORTION ADJ. 0-63 36 36 39
9 BLK0 VERTICAL BLANKING ON/OFF 0, 1 0 0
10 VMLV VELOCITY MODULATION LEVEL 0-3 Palette mode controls this register 2
11 AGN2 AGING 2 0, 1 0 0
12 REFP REFERENCE PULSE POSITION 0, 1 0 0
13 VBLK VERTICAL BLANKING ON/OFF 0, 1 0 0
14 JPSW 0, 1 0 0
15 VSIZ VERTICAL SIZE ADJ. 0-63 47 47 49
16 VPOS VERTICAL POSITION ADJ. 0-63 32 32 32
17 VLIN VERTICAL LINEARITY ADJ. 0-15 6 6
18 SCOR VERTICAL “S” CORRECTION ADJ. 0-15 8 8
19 VZOM 16:9 CRT Z MODE ON/OFF 0, 1 0 0
20 EHT VRT HI-VOLT. CORRECTION 0-15 6 6
21 ASP ASPECT RATIO CONTROL 0-63 47 47
22 SCRL 16:9 CRT Z MODE TRANS SCROLL 0-63 31 31
23 HBLK HORIZONTAL BLANKING ON/OFF 0, 1 1 1
24 LBLK LEFT BLANKING ADJ. 0-15 12 12
25 RBLK RIGHT BLANKING ADJ. 0-15 5 5
26 VUSN V SAW WAVEFORM COMPRESS 0, 1 0 0
27 HDW H. DRIVE PULSE WIDTH 0, 1 1 1
28 EWDC “PARABOLA” EW/DC ADJ. 0, 1 0 0
29 LVLN LOWER SCREEN BTM VRT LIN ADJ. 0-15 0 0
30 UVLN UPPER SCREEN BTM VRT LIN ADJ. 0-15 0 0
31 RDRV R OUTPUT DRIVE CONTROL 0-63 31 36
32 GDRV G OUTPUT DRIVE CONTROL 0-63 25 26
33 BDRV B OUTPUT DRIVE CONTROL 0-63 25 25
34 RCUT R OUTPUT CUTOFF CONTROL 0-15 10 8
35 GCUT G OUTPUT CUTOFF CONTROL 0-15 7 6
36 BCUT B OUTPUT CUTOFF CONTROL 0-15 6 7
37 DCOL DYNAMIC COLOR ON/OFF 0, 1 0 1
38 SHUE SUB HUE 0-31 14 15
39 SCOL SUB COLOR 0-31 14 14 15
40 SBRT SUB BRIGHTNESS 0-31 15 15
41 RON R OUTPUT ON/OFF 0, 1 1 1
42 GON G OUTPUT ON/OFF 0, 1 1 1
43 BON B OUTPUT ON/OFF 0, 1 1 1
44 AXPL AXIS PAL 0, 1 0 0
45 AXNT AXIS NTSC 0, 1 0 0
46 CBPF CHROMA BPF ON/OFF 0, 1 0 1
47 CTRP Y TRAP FILTER ON/OFF 0, 1 1 1
48 COFF COLOR ON/OFF 0, 1 0 0
49 KOFF SET COLOR KILLER 0, 1 0 0
50 SSHP SUB SHARPNESS 0-15 6 7
51 SHPF SHARPNESS CIRCUIT F0 0, 1 1 1
52 PREL PRE/OVR SHOOT SWITCHING 0, 1 1 1 1
53 Y-DC DC TRANS RATIO SWITCHING 0, 1 1 1
54 GAMM GAMMA CORRECTION AMNT 0-3 Palette mode controls this register 1
55 ABLM ABL MODE SWITCHING 0, 1 1 1
56 VTH ABL CD VHT SWITCHING 0, 1 1 1
57 YDEL Y DELAY TIME CONTROL 0-15 7 7
58 NCOL NO COLOR ID 0, 1 1 1
59 FSC FSC OUT ON/OFF 0, 1 1 1
60 K-ID KILLER ID CONTROL SW 0, 1 0 0
61 HOSC H VCO OSCILLATION FREQ 0-15 7 7
62 VSS V SYNC SLICE LEVEL 0, 1 1 0
To Next Page
