KDL-22BX320/22BX321
KDL-22BX320/22BX321 31
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
When ordering parts by reference
number, please include the board name.
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: The components identied by a red outline and a mark
contain condential information. Specic instructions must
be adhered to whenever these components are repaired and/or
replaced.
See Appendix A: Encryption Key Components in the back of this
manual.
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
SECTION 2: ELECTRICAL PARTS LIST
ACCESSORIES AND PACKING
4-273-518-01 BAG, PROTECTION (GW22)
(KDL-22BX320 US ONLY)
4-272-316-21 CARTON, INDIVIDUAL
(KDL-22BX320 US ONLY)
4-269-377-01 CUSHION, LOWER (GW22)
(KDL-22BX320 US ONLY)
4-269-376-01 CUSHION, UPPER (GW22)
(KDL-22BX320 US ONLY)
4-292-075-01 LABEL, ENERGY GUIDE (GEM)
(KDL-22BX320 US ONLY)
A
1-857-903-11 A BOARD, COMPLETE
Component level repair information is not available.
GD8
1-857-895-11 GD8 (POWER) BOARD, COMPLETE
Component level repair information is not available.
H
1-857-898-21 H BOARD, COMPLETE
Component level repair information is not available.
