5-6
DVP-NS47P/NS57P/NS508P/NS64P/NS67P/NS608P
Pin No. Pin name Type Function
106 DISC/EXT Analog DISC/External input select output signal (H: DISC, L: EXTin)
107 ADVCM Analog 2ch audio ADC reference voltage
108 RGBSEL/ MIC ADIN 1 Analog 1. RGB/YCbCr select output signal
(H:RGB Disable, L:RGB Enable) - MV-58 Only
2. Audio ADC input 1 - MV-57 Karaoke Only
109 AADVDD Power 3.3V Power pin for 2ch audio ADC circuitry
110 APLLVDD3 Power 3.3V Power pin for audio clock circuitry
111 APLLCAP Analog InOut APLL External Capacitance connection
112 ADACVSS2 Ground Ground pin for audio DAC circuitry
113 ADACVSS1 Ground Ground pin for audio DAC circuitry
114 EUROVY/KARMOD Analog Output 1. CVBS/S terminal select output signal (H: CBVS, L: S-terminal)
2. Karaoke Mode Detect Signal (H: Karamod On, L: Karamod Off)
115 LIMITSW Analog Output BU Limit Switch
116 AR Analog Output Audio DAC Right Channel Output
117 AVCM Analog Audio DAC Reference voltage
118 AL Analog Output Audio DAC Left Channel Output
119 MUTE123 Analog Output Motor drive channel 1,2 & 3 mute
120 TSD_M Analog Output Motor driver thermal shutdown sensor (Active Low)
121 ADACVDD1 Analog Power 3.3V Power pin for audio DAC circuitry
122 ADACVDD2 Analog Power 3.3V Power pin for audio DAC circuitry
123 AVDD18_1 Analog Power Analog 1.8V power
124 AGND18_1 Analog Ground Analog Ground
125 RFIP Analog Input AC Coupled DVD RF signal input RFIP
126 NC Analog Input Not Used
127 IOPMON Analog Input Main beam, RF AC input path
128 SPFG Analog Input Main beam, RF AC input path
5-6E
