4-18
DSC-H50_L2
ST-195, DC-111, PL-051, LE-042
Note:FL901(FLASH UNIT) is not
included in ST-195 flexible
complete board.
LND003
LND002
LND001
R001
1M
LND006
XE_-
LND005
XE_+
LND004
TRIGGER
L001
1
2
3
C002
0.047u
250V
XE_H
1
2
3
REG_GND
XE_L
A
3
A
C C
241
08
B B
FLASH UNIT
of LEVEL2
PAGE 4-17
FLEXIBLE
ST-194
LND201-LND203
FL901
FLASH UNIT
ST-195 FLEXIBLE BOARD
HARNESS
(PINK)
SOLDERING
HARNESS
(WHITE)
SOLDERING
HARNESS
(BLUE)
SOLDERING
Note:BH001, BT001, and J001 are not included
in DC-111 flexible complete board.
LND017
ACV_UNREG
LND016
ACV_UNREG
LND018
ACV_UNREG
LND019
ACV_UNREG
LND020
BATT_XEXT
J001
1
3
2
4
5
BT001
LND014
REG_GND
C001
0.022u
FB001
LF001
1
2
3
4
R001
1k
C002
0.022u
LND001
VL_3V
LND024
Batt_UNREG
LND025
Batt_SIG
LND026
Batt_GND
LND004
BATT_UNREG
LND010
REG_GND
LND006
BATT_UNREG
LND009
BATT_SIG
LND012
REG_GND
LND011
REG_GND
LND005
BATT_UNREG
LND013
REG_GND
LND008
BATT_UNREG
LND007
BATT_UNREG
R002
33
LND002
REG_GND
LND015
REG_GND
LND003
BATT_UNREG
BATTERY IN, DC IN
2
1
of LEVEL3
PAGE 4-14
18
(10/10)
3
20
Pin
SY-201
CN712
19
DC JACK
BH001
BATTERY
TERMINAL
DC IN
s
BOARD
LITHIUM
RECHARGEABLE
BATTERY
DC-111 FLEXIBLE BOARD
A
3
A
C C
241
08
B B
Note:RY301 is not included in PL-051 complete board.
C
C301
1u
CN301 6P
1
2
3
4
5
6
D301
MA2S1110G8S0
D302
XX
3
2
1
S301
12
4
3
RY301
1
2
REG_GND
STRB_PLUNGER
REG_GND
XSTRB_POPUP
STRB_PLUNGER
REG_GND
XX MARK:NO MOUNT
STROBE PLUNGER
of LEVEL3
PAGE 4-14
(10/10)
SY-201
CN704
STROBE POPUP
DETECT
PLUNGER SOLENOID
PL-051 BOARD
(STROBE OPEN)
A
3
A
C C
241
08
B B
D001
CL-330IRS2-X-TU
LND003
LND001
LND006
LND004
LND002
LND005
D002
CL-360S-TD4-X-TL
5
4
3
1
2
6
XAF_LED
AF_5V
NS_Vcc
XNS_LED
NS_Vcc
AF_5V
NIGHTSHOT, AF ILLUMINATOR
1
of LEVEL3
PAGE 4-14
(10/10)
6
Pin
SY-201
CN706
AF ILLUMINATOR/
SELF-TIMER
(NIGHTSHOT)
LE-042 FLEXIBLE BOARD
A
3
A
C C
241
08
B B
• Refer to page 4-2 (English), 4-3 (Japanese) for mark 0.
