2-4
DSC-H50_L2
2-2-2. FRONT PANEL SECTION-1
Follow the disassembly in the numerical order given.
1 Loudspeaker (1.3cm) (1-1 to 1-3)
2 SY-201 Board (2-1 to 2-16)
3 Lens Block (3-1 to 3-3)
HARDWARE LIST
SY-201
SY-201
H
G
F
H
G
E
D
C
B
A
J
I
F
E
C
A
I
J
H
B
G
D
1-1
(Claw)
1-2
1-3
1
Loudspeaker
(1.3cm)
2
SY-201 Board
3
Lens Block
2-11
(#76)
2-12
(Claw)
2-13
(Claw)
2-1
2-5
2-8
2-102-92-3
2-4
2-6
2-7
2-16
2-15
2-14
2-2 (Claw)
3-1 (#76)
3-2
(#74)
3-3 (Claw)
HELP02
HELP04
HELP03
HELP03
Note: High-voltage cautions
Discharging the Capacitor
Short-circuit between the two points with
the short jig about 10 seconds.
To avoid the spark with the metal plate,
wrap the short jig with the insulation tape.
ST-194 Board
R:1 kΩ/1 W
(Part code: 1-215-869-11)
Note:
On installation of the lens block,
adjust the position of the night
shot switch.
Front Panel
Section-2
(See Page 2-5)
To Next Page
