2-3
DSC-H50_L2
2-2. DISASSEMBLY
2-2-1. OVERALL SECTION
Follow the disassembly in the numerical order given.
1 Cabinet (Rear) Section (1-1 to 1-10)
2 Retainer SW (2-1)
3 Side Cabinet (R) Block (3-1 to 3-2)
HELP
HELP
EXPLODED VIEW
HARDWARE LIST
1-2
(#2/10)
1-9
(Claw)
1-10
1-3
(#2/10)
1-8
1-1
(#2/10)
1-5
(#23/#76)
1-6
(#23/#76)
1-7
1-4
(Open the
LCD panel)
1 Cabinet (Rear)
Section
(See Page 2-7)
2 Retainer SW
3
Side Cabinet (R)
Block
2-1
3-2
(#2/#10)
3-1
HELP01
HELP01
Front Panel Section-1
(See Page 2-4)
