2-6
DSC-H50_L2
2-2-4. FRONT PANEL SECTION-3
Follow the disassembly in the numerical order given.
1 Control Switch Block (1-1 to 1-4)
2 Front Panel Block (2-1 to 2-5)
EXPLODED VIEW
HARDWARE LIST
SI-115 Flexible Board
Attach SI-115 flexible board to microphone
holder as shown in the figure.
Microphone Holder
2-1
(#76)
2-3
(#76)
1-1
(#76)
1-3
(Claw)
2-2
1-4
2-4
2-5
1 Control Switch Block
2
Front Panel Block
HELP03
1-2
