5-10
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-H50_L2
• Refer to page 5-1 for mark 0.
1-875-545-11 PB-052 FLEXIBLE BOARD
********************
(S001 and S002 are not supplied, but there are included in PB-052 flexible board.)
< SWITCH >
S001 (not supplied) SWITCH (PLAYBACK)
S002 (not supplied) SWITCH (SLIDESHOW)
************************************************************
A-1519-819-A PL-051 BOARD, COMPLETE
**********************
(RY301 is not included in PL-051 complete board.)
< CAPACITOR >
C301 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN301 1-817-554-51 CONNECTOR, FFC/FPC 6P
< DIODE >
* D301 6-501-947-01 DIODE MA2S1110G8S0
< SWITCH >
S301 1-786-179-31 SWITCH, PUSH (1KEY)
(STOROBE POPUP DETECT)
< PLUNGER SOLENOID >
* RY301 1-455-056-11 SOLENOID, PLUNGER (STROBE OPEN)
************************************************************
A-1519-827-A SI-115 FLEXIBLE BOARD, COMPLETE
******************************
< CAPACITOR >
C001 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< IC >
IC001 6-600-163-01 IC RS-770
< SWITCH >
* S002 1-786-914-31 SWITCH, TACTILE (FINDER/LCD)
************************************************************
A-1519-820-A ST-194 BOARD, COMPLETE
**********************
(C205 (CHARGING CAPACITOR) is not included in ST-194 complete board.)
< CAPACITOR >
C201 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C202 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C203 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
0C205 1-114-341-21
CAP, ALUMINUM ELECT
180uF 99% 315V
C207 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN201 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
< DIODE >
0*D202 6-502-219-01 DIODE FV02R80TP
D204 6-500-619-01 DIODE RB520S-40TE61
< IC >
IC201 6-707-555-01 IC TPS65552RGTR
< COIL >
L201 1-456-499-11 INDUCTOR 4.7uH
< TRANSISTOR >
0*Q201 6-551-702-01 TRANSISTOR RJP4003ASA-00-Q0
Q202 6-551-304-01 TRANSISTOR MTM231230LSO
Q203 6-550-119-01 TRANSISTOR DTC144EMFS6T2L
< RESISTOR >
R203 1-218-989-11 RES-CHIP 1M 5% 1/16W
R204 1-218-940-11 RES-CHIP 82 5% 1/16W
R207 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R208 1-218-977-11 RES-CHIP 100K 5% 1/16W
R209 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
< TRANSFORMER >
0 T201 1-445-108-21 TRANSFORMER, D.C-D.C CONVERTER
************************************************************
A-1519-828-A ST-195 FLEXIBLE BOARD, COMPLETE
******************************
(FL901 (FLASH UNIT) is not included in ST-195 flexible complete board.)
< CAPACITOR >
0 C002 1-100-758-11 CERAMIC CHIP 0.047uF 10% 250V
< FLASH UNIT >
0 FL901 1-480-062-21 FLASH UNIT
< COIL >
0*L001 1-457-498-21 TRIGGER COIL
< RESISTOR >
0 R001 1-216-121-00 RES-CHIP 1M 5% 1/10W
************************************************************
A-1519-821-A SW-532 BOARD, COMPLETE
***********************
< CAPACITOR >
C108 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN101 1-816-684-51 CONNECTOR, FFC/FPC (ZIF) 8P
* CN102 1-816-659-51 FFC/FPC CONNECTOR (LIF) 6P
* CN103 1-816-659-51 FFC/FPC CONNECTOR (LIF) 6P
< RESISTOR >
R101 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
SW-532ST-195ST-194
SI-115PL-051PB-052
