Sony RMT-V259 - SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS; MA-373 BOARD Component List

4-74-7
JK-180
(SE500/SE800/
SX800)
(FRONT IN)
DS-91
(MODE CONTROL)
POWER BLOCK
(SRV938EK)
(POWER SUPPLY)
KK-23
(SE800/SX800)
(DIAL TIMER)
MA-373
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL,
TUNER, MODE CONTROL
(
)
MA-373 BOARD
CN101 A-2
CN102 E-2
CN104 H-4
CN161 I-11
CN260 B-9
CN261 B-9
CN262 A-6
CN263 E-11
CN350 B-7
CN351 B-7
CN460 J-1
CN461 J-1
CN500 A-11
CN501 J-11
CN570 B-11
CN600 G-1
CN601 I-1
D100 F-6
D110 B-3
D140 I-8
D420 J-9
D421 J-9
D422 J-10
D423 J-10
D424 J-13
D500 B-10
D501 B-12
D502 A-11
D503 A-11
D504 A-11
D570 B-11
D571 A-12
D572 A-11
D573 A-5
D590 D-9
D591 D-9
D603 E-1
D606 I-2
D607 J-11
D700 F-12
D702 C-13
D750 H-13
D800 G-6
IC001 F-5
IC130 H-4
IC160 H-12
IC161 I-11
IC162 H-9
IC200 D-6
IC260 A-6
IC301 B-9
IC350 C-6
IC420 I-6
IC460 J-4
IC580 D-11
IC601 I-12
IC850 G-13
IC970 B-4
Q100 F-10
Q101 F-1
Q102 F-5
Q103 I-9
Q104 I-9
Q140 H-8
Q200 E-5
Q201 E-5
Q202 E-8
Q203 E-7
Q204 D-5
Q270 B-8
Q350 C-6
Q380 B-6
Q390 C-8
Q391 C-8
Q392 B-8
Q501 C-11
Q502 D-11
Q510 C-11
Q520 B-12
Q540 C-11
Q541 D-11
Q580 E-10
Q581 E-10
Q582 E-10
Q583 D-11
Q590 C-10
Q591 D-10
Q592 D-9
Q607 E-1
Q608 E-1
Q612 J-12
Q613 I-12
Q660 F-8
Q661 G-9
Q700 F-12
Q701 F-13
Q702 E-13
Q720 D-12
Q721 D-12
Q730 F-13
Q731 F-12
Q751 B-12
Q752 B-13
Q800 G-6
Q801 H-6
Q802 G-6
Q803 G-6
Q804 H-7
Q850 G-12
Q970 C-4
Q972 D-4
Q973 D-4
Q974 C-5
Q975 D-4
Q976 D-4
