Sony RMT-V402A - Bottom View

–
5 –
1-1-2 Bottom View
Œ
´ˇ
¨
ˆ
Ø
∏
”
’
˝
Fig. 1-3 Bottom Parts Location
ΠGEAR JOINT 1
´ GEAR JOINT 2
ˇ BRACKET GEAR
¨ MOTOR CAPSTAN ASS’Y
ˆ LEVER T LOAD ASS’Y
Ø GEAR LOADING DRIVE
∏ LEVER S LOAD ASS’Y
” HOLDER CLUTCH ASS’Y
’ BELT PULLEY
˝ SLIDER CAM
