Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT380/CT381
64
CN3001 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3002 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN3100 1-821-398-41 HDMI CONNECTOR (HDMI IN 3)
CN3101 1-821-398-41 HDMI CONNECTOR (HDMI IN 1)
CN3102 1-821-398-41 HDMI CONNECTOR (HDMI IN 2)
CN3106 1-821-398-41 HDMI CONNECTOR (ARC HDMI OUT)
< DIODE >
* D1001 6-503-578-01 DIODE RB520SM-30T2R
* D1002 6-503-578-01 DIODE RB520SM-30T2R
* D1004 6-503-578-01 DIODE RB520SM-30T2R
D1005 6-502-961-01 DIODE DA2J10100L
D1008 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D1009 6-502-961-01 DIODE DA2J10100L
D1010 6-503-761-01 DIODE RB751S40, 115
D1011 6-503-196-01 LED CL-194S-HB8SP-SD-T
(BLUETOOTH INDICATOR)
* D2003 6-503-578-01 DIODE RB520SM-30T2R
* D2005 6-503-578-01 DIODE RB520SM-30T2R
D3001 6-504-123-01 DIODE KDZVTR5.6B
D3002 6-502-961-01 DIODE DA2J10100L
D3003 6-503-040-01 DIODE DZ2J300M0L
D3103 8-719-053-18 DIODE 1SR154-400TE-25
D3104 8-719-053-18 DIODE 1SR154-400TE-25
< EARTH TERMINAL >
* ET3001 1-780-408-11 TERMINAL, LUG
* ET3002 1-780-408-11 TERMINAL, LUG
< FUSE >
0 F3001 1-523-039-11 FUSE (5 A/32 V)
0 F3002 1-523-039-11 FUSE (5 A/32 V)
< FERRITE BEAD >
FB1001 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1003 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1004 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1005 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1006 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1007 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1008 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1009 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1010 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB1012 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB2001 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB2003 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB2004 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB2005 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3102 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB3103 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3104 1-400-921-21 FERRITE, EMI (SMD)
FB3105 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3502 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
FB3504 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
< FILTER >
FL2001 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL2002 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC1001 6-721-894-01 IC BR24G16FJ-3GTE2
IC1002 A-2076-761-A IC R5F3650RDFB#30 (SV) (See Note 1)
IC1003 6-713-333-01 IC PST8429UL
IC1008 6-717-680-01 IC BD00IC0WEFJ-E2
IC1009 (Not supplied) IC RT8295ALZSP (See Note 2)
IC1010 (Not supplied) IC MFI337S3959 (See Note 2)
IC1011 6-712-825-01 IC R1154N001C-TR-FE
IC1012 (Not supplied) IC BMA250E (Except US, CND) (See Note 2)
IC1013 6-719-198-01 IC MM3411A33URE
IC2003 8-759-596-39 IC SN74LV4052APWR
IC2004 6-707-010-01 IC NJM2740V (TE2)
IC2005 6-716-745-01 IC PCM9211PTR
IC2006 6-718-999-01 IC MM1839A50NRE
IC2007 6-719-198-01 IC MM3411A33URE
IC2008 (Not supplied) IC W25Q16DVSSIG (See Note 2)
IC2009 (Not supplied) IC ADSST-AVR-3045 (See Note 2)
IC2010 6-707-870-01 IC TC74VHC157FT (EK)
IC2011 6-710-388-01 IC 74LVC1G79GW-125
IC2012 6-717-879-01 IC RT8293ALZSP
IC2013 6-704-099-01 IC TC7WZ08FK
IC2014 8-759-655-22 IC TC7WH34FK
IC3001 6-721-021-01 IC TAS5624ADDVR (See Note 3)
IC3002 6-718-105-01 IC TAS5534DGGR
IC3003 6-718-377-01 IC BD00C0AWFP-E2
IC3102 6-719-139-01 IC MM3411A50NRE
IC3105 6-717-680-01 IC BD00IC0WEFJ-E2
IC3106 6-717-680-01 IC BD00IC0WEFJ-E2
IC3107 6-718-999-01 IC MM1839A50NRE
IC3109 (Not supplied) IC SII9535CTUC (See Note 2)
IC3201 6-709-888-01 IC TC7WHU04FK
IC3705 6-717-879-01 IC RT8293ALZSP
< JACK >
* J2001 1-842-576-11 MINI JACK (RA) (ANALOG IN)
< JUMPER RESISTOR >
JC3001 1-216-864-11 SHORT CHIP 0
JC3002 1-216-864-11 SHORT CHIP 0
JC3003 1-216-864-11 SHORT CHIP 0
JC3004 1-216-864-11 SHORT CHIP 0
JC3005 1-216-864-11 SHORT CHIP 0
JC3007 1-216-864-11 SHORT CHIP 0 (Except US, CND)
JC3012 1-216-864-11 SHORT CHIP 0
< COIL >
L1002 1-400-789-21 INDUCTOR 2.2uH
L1003 1-460-601-11 COIL, CHOKE 10uH
L2001 1-481-524-11 INDUCTOR 10uH
L2002 1-481-524-11 INDUCTOR 10uH
L2003 1-481-524-11 INDUCTOR 10uH
L2004 1-400-922-11 INDUCTOR 220uH
L2005 1-412-975-31 INDUCTOR 0.47uH
L2006 1-460-601-11 COIL, CHOKE 10uH
L2007 1-400-791-21 INDUCTOR 10uH
Note 2: IC1009, IC1010, IC1012, IC2008, IC2009 and IC3109 on the
MAIN board cannot replace with single. When these parts are
damaged, replace the complete mounted board.
Note 3: When the IC3001 on the MAIN board is replaced, refer to
“NOTE OF REPLACING THE IC3001 ON THE MAIN
BOARD AND THE COMPLETE MAIN BOARD” on page 5.
MAIN
Note 1: When IC1002 on the MAIN board is replaced, refer to
“NOTES ON THE WIRELESS CONNECTION (LINK)
AFTER REPAIRS ARE COMPLETE” on page 5.
Ver. 1.1
