Sony SA-CT381 - DISASSEMBLY; DISASSEMBLY FLOW

HT-CT380/CT381
7
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-14. CHASSIS (MAIN) BLOCK
(Page 20)
2-12. POWER CORD (AC1)
(Page 18)
2-13. BLUETOOTH MODULE (BT1)
(Page 19)
2-8. KEY BOARD BLOCK
(Page 14)
2-9. BUTTON, KEY BOARD
(Page 15)
2-11. MAIN BOARD
(Page 17)
2-2. CABINET TOP BLOCK
(Page 8)
2-15. SERVICE POSITION
(Page 21)
2-3. LOUDSPEAKER (6 cm) (L-CH, R-CH) (SP1, SP2)
(Page 9)
2-4. NFC MODULE (NFC1)
(Page 10)
2-5. DISPLAY BOARD
(Page 11)
2-6. POWER BOARD
(Page 12)
2-7. CONNECTION CABLE WITH SPEAKER
(L-CH, R-CH) (SPC1, SPC2)
(Page 13)
2-10. RF MODULATOR (RF1)
(Page 16)
