Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT380/CT381
68
R3155 1-216-864-11 SHORT CHIP 0
R3162 1-216-864-11 SHORT CHIP 0
R3176 1-216-864-11 SHORT CHIP 0
R3182 1-216-864-11 SHORT CHIP 0
R3187 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3188 1-218-941-81 METAL CHIP 100 5% 1/16W
* R3189 1-250-523-11 METAL CHIP 15K 1% 1/16W
R3190 1-250-535-11 METAL CHIP 47K 1% 1/16W
R3191 1-218-941-81 METAL CHIP 100 5% 1/16W
R3192 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3193 1-218-941-81 METAL CHIP 100 5% 1/16W
R3194 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3195 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
R3198 1-218-990-81 SHORT CHIP 0
R3199 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R3201 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3202 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3203 1-218-941-81 METAL CHIP 100 5% 1/16W
R3204 1-218-941-81 METAL CHIP 100 5% 1/16W
R3205 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3206 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3209 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3211 1-218-990-81 SHORT CHIP 0
R3212 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3213 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3214 1-218-937-11 METAL CHIP 47 5% 1/16W
R3215 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R3216 1-218-941-81 METAL CHIP 100 5% 1/16W
R3217 1-218-981-81 METAL CHIP 220K 5% 1/16W
R3218 1-218-990-81 SHORT CHIP 0
R3219 1-218-949-11 METAL CHIP 470 5% 1/16W
R3220 1-218-990-81 SHORT CHIP 0
R3221 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R3228 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3229 1-216-797-11 METAL CHIP 10 5% 1/10W
R3231 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3232 1-216-797-11 METAL CHIP 10 5% 1/10W
R3235 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3236 1-220-208-81 METAL CHIP 130K 5% 1/16W
R3248 1-216-864-11 SHORT CHIP 0
R3250 1-216-864-11 SHORT CHIP 0
R3260 1-218-937-11 METAL CHIP 47 5% 1/16W
R3261 1-218-937-11 METAL CHIP 47 5% 1/16W
R3262 1-218-937-11 METAL CHIP 47 5% 1/16W
R3263 1-218-937-11 METAL CHIP 47 5% 1/16W
R3264 1-218-937-11 METAL CHIP 47 5% 1/16W
R3272 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3273 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3274 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3275 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3283 1-218-990-81 SHORT CHIP 0
R3284 1-218-937-11 METAL CHIP 47 5% 1/16W
R3285 1-218-947-11 METAL CHIP 330 5% 1/16W
R3287 1-218-941-81 METAL CHIP 100 5% 1/16W
R3288 1-218-941-81 METAL CHIP 100 5% 1/16W
R3291 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3293 1-216-864-11 SHORT CHIP 0
R3294 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3295 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3296 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3297 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3300 1-218-937-11 METAL CHIP 47 5% 1/16W
R3301 1-218-947-11 METAL CHIP 330 5% 1/16W
R3302 1-218-965-11 METAL CHIP 10K 5% 1/16W
* R3303 1-250-527-11 METAL CHIP 22K 1% 1/16W
* R3304 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
* R3305 1-250-503-11 METAL CHIP 2.2K 1% 1/16W
R3306 1-218-990-81 SHORT CHIP 0
R3413 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3414 1-216-797-11 METAL CHIP 10 5% 1/10W
R3415 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3418 1-216-864-11 SHORT CHIP 0
R3419 1-216-864-11 SHORT CHIP 0
* R3725 1-250-523-11 METAL CHIP 15K 1% 1/16W
* R3726 1-250-523-11 METAL CHIP 15K 1% 1/16W
* R3727 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R3728 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3729 1-218-953-11 METAL CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB3108 1-200-035-21 RES, NETWORK 4.7 (1005X4)
RB3109 1-200-035-21 RES, NETWORK 4.7 (1005X4)
< VIBRATOR >
X1001 1-795-313-21 VIBRATOR, CERAMIC (8 MHz)
X2001 1-814-882-11 QUARTZ CRYSTAL UNIT (24.576 MHz)
X2002 1-814-883-11 QUARTZ CRYSTAL UNIT (25 MHz)
X3101 1-814-884-11 QUARTZ CRYSTAL UNIT (27 MHz)
*************************************************************
A-2063-682-A POWER BOARD, COMPLETE (US, CND)
(See Note)
A-2063-683-A POWER BOARD, COMPLETE (Except US, CND)
(See Note)
**********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
0 C902 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND) (See Note)
0 C903 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND) (See Note)
0 C904 1-114-594-21 FILM 0.22uF 10% 310V
(US, CND) (See Note)
0 C905 1-116-397-21 FILM 0.33uF 10% 310V
(Except US, CND) (See Note)
0 C906 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(Except US, CND) (See Note)
0 C907 1-116-397-21 FILM 0.33uF 10% 310V
(Except US, CND) (See Note)
0 C908 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(Except US, CND) (See Note)
0 C914 1-120-080-11 ELECT (BLOCK) 330uF 200V
(US, CND) (See Note)
0 C915 1-118-715-11 ELECT (BLOCK) 100uF 20 % 450V
(Except US, CND) (See Note)
0 C930 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
0 C931 1-164-217-91 CERAMIC CHIP 150PF 5% 50V
(US, CND)
0 C931 1-164-218-91 CERAMIC CHIP 180PF 5% 50V
(Except US, CND)
0 C932 1-118-343-11 CERAMIC CHIP 4700PF 10% 50V
MAIN POWER
Note: When C902 to C908, C914, C915 on the POWER board and the complete POWER
board are replaced, refer to “BOND FIXATION OF ELECTRIC PARTS” on page 6.
