29
GB
Others
4 Put a check the checkbox
beside [UPnP User Interface],
then click [OK].
5 Click [Next].
The [Completing the Windows
Components Wizard] window appears.
6 Click [Finish].
Specifications
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 4 ohm loads,driven from 100 - 20 kHz;
rated 1.5 watts minimum RMS power,with no
more than 1 % total harmonic distortion from
100 milliwatts to rated output.
Wireless LAN section
Compatible standards:
IEEE 802.11 b/g
(WEP 64 bit, WEP 128 bit,
WPA/WPA2-PSK (AES),
WPA/WPA2-PSK (TKIP))
Radio frequency:
2.4 GHz
Inputs/Outputs
Speakers
Approx. 50 mm (2 in) diameter × 1
AUDIO IN jack:
Stereo mini jack
Voltage: 1.0 V
Network port:
10BASE-T/100BASE-T (Auto Polarity)
General
Power requirements:
AC adaptor
Input: 100-240V AC, 50/60Hz
Output: DC5.2V 2A
Dimensions (w/h/d) (including
projecting parts and controls):
Approx. 141 × 141 × 123 mm
(Approx. 55/8 × 55/8 × 47/8 in)
