Sony SA-TS22W - GENERAL INFORMATION; Surround Speaker Functionality

3
SA-TS22W
SECTION 1
GENERAL
Surround speaker (L)
The surround speaker (L) incorporates the IR receiver. It receives the sound from the IR transmitter and
sends it to the surround speaker (R).
Connect the surround speaker (R).
ON
OFF
ONLY FOR
POWER
DIR-R2
Rear side of the surround speaker (L)
IR receiver
This section is extracted
from instruction manual.
SERVICING NOTE
4-246-444-01
After service, as shown in a figure,
a power cord is fixed.
power cord
Label
