9
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN POWER IC
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-441-11 CARBON 100K 5% 1/4W
R103 1-249-441-11 CARBON 100K 5% 1/4W
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-424-11 CARBON 3.9K 5% 1/4W F
R107 1-249-436-11 CARBON 39K 5% 1/4W
R108 1-249-424-11 CARBON 3.9K 5% 1/4W F
R109 1-249-417-11 CARBON 1K 5% 1/4W F
R110 1-249-435-11 CARBON 33K 5% 1/4W
R111 1-249-425-11 CARBON 4.7K 5% 1/4W F
R112 1-249-439-11 CARBON 68K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-249-417-11 CARBON 1K 5% 1/4W F
R115 1-249-435-11 CARBON 33K 5% 1/4W
R116 1-249-438-11 CARBON 56K 5% 1/4W
R117 1-249-427-11 CARBON 6.8K 5% 1/4W F
R118 1-249-427-11 CARBON 6.8K 5% 1/4W F
R119 1-249-427-11 CARBON 6.8K 5% 1/4W F
R303 1-249-427-11 CARBON 6.8K 5% 1/4W F
R304 1-249-433-11 CARBON 22K 5% 1/4W
R305 1-249-412-11 CARBON 390 5% 1/4W F
R307 1-249-478-81 CARBON 2.2 5% 1/2W
R308 1-249-433-11 CARBON 22K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-427-11 CARBON 6.8K 5% 1/4W F
R313 1-249-429-11 CARBON 10K 5% 1/4W
R314 1-215-892-11 METAL OXIDE 1K 5% 2W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-430-11 CARBON 12K 5% 1/4W
R318 1-215-868-00 METAL OXIDE 680 5% 1W
R401 1-216-456-00 METAL OXIDE 820 5% 2W
R402 1-216-456-00 METAL OXIDE 820 5% 2W
< RELAY >
RY301 1-515-920-11 RELAY (24V)
**************************************************************
1-678-477-11 POWER IC BOARD
***************
< CAPACITOR >
C304 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN108 1-785-088-11 PIN, CONNECTOR 6P
< IC >
IC301 8-759-299-53 IC LM3886T
< RESISTOR >
R306 1-249-435-11 CARBON 33K 5% 1/4W
**************************************************************
1-678-474-11 POWER SUPPLY BOARD
********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
0 C2 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
CN101 1-564-321-00 PIN, CONNECTOR 2P
* CN102 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< FUSE >
0 F401 1-532-500-31 FUSE TL 0.63A/250V
**************************************************************
1-678-476-11 POWER SWITCH BOARD
********************
< CAPACITOR >
0 C1 1-113-915-11 CERAMIC 0.001uF 20.00% 250V
< CONNECTOR >
* CN201 1-695-044-11 PIN, CONNECTOR 2P
< SWITCH >
0 S1 1-554-920-61 SWITCH, PUSH (AC POWER)(1 KEY)(POWER)
**************************************************************
MISCELLANEOUS
**************
0 56 1-777-071-11 CORD, POWER
103 1-694-516-11 TERMINAL, SPEAKER
SP1 1-529-764-11 SPEAKER (16cm)
SP2 1-529-763-11 SPEAKER (5cm)
0 T401 1-435-608-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK, HK)
POWER SUPPLY POWER SWITCH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
