8
SECTION 3
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
CONTROL LED MAIN
1-678-475-11 CONTROL BOARD
**************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
* CN202 1-564-519-11 PLUG, CONNECTOR 4P
< VARIABLE RESISTOR >
RV201 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
**************************************************************
1-678-478-11 LED BOARD
**********
* 4-937-336-32 HOLDER, LED
< CONNECTOR >
CN801 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D801 8-719-080-25 DIODE SEL6414LF62 (POWER)
**************************************************************
A-4473-638-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
C102 1-126-964-11 ELECT 10uF 20.00% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-136-167-00 MYLAR 0.15uF 5.00% 50V
C105 1-136-159-00 MYLAR 0.033uF 5.00% 50V
C106 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C107 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C108 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C109 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C110 1-136-164-00 MYLAR 0.082uF 5.00% 50V
C111 1-136-168-00 MYLAR 0.18uF 5.00% 50V
C112 1-126-964-11 ELECT 10uF 20.00% 50V
C301 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C302 1-126-933-11 ELECT 100uF 20.00% 16V
C305 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C306 1-162-215-31 CERAMIC 47PF 5% 50V
C307 1-126-967-11 ELECT 47uF 20.00% 50V
C308 1-126-967-11 ELECT 47uF 20.00% 50V
C309 1-104-665-11 ELECT 100uF 20.00% 10V
C310 1-126-963-11 ELECT 4.7uF 20.00% 50V
C311 1-104-664-11 ELECT 47uF 20.00% 25V
C401 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C402 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C403 1-119-940-51 ELECT 4700uF 20.00% 50V
C404 1-119-940-51 ELECT 4700uF 20.00% 50V
C405 1-104-665-11 ELECT 100uF 20.00% 25V
C406 1-104-665-11 ELECT 100uF 20.00% 25V
< CONNECTOR >
* CN104 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
* CN105 1-568-951-11 PIN, CONNECTOR 2P
CN106 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN109 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
< DIODE >
D301 8-719-911-19 DIODE 1SS133T-72
D302 8-719-911-19 DIODE 1SS133T-72
D303 8-719-911-19 DIODE 1SS133T-72
D304 8-719-911-19 DIODE 1SS133T-72
D401 8-719-025-03 DIODE RBA-402
D402 8-719-068-44 DIODE HZ15BP-TK
D403 8-719-068-44 DIODE HZ15BP-TK
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-634-50 IC M5218AL
IC103 8-759-634-50 IC M5218AL
IC302 8-759-111-68 IC uPC1237HA
< JACK >
J101 1-770-377-31 JACK, PIN 1P (LINE)
< TRANSISTOR >
Q101 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q102 8-729-119-78 TRANSISTOR 2SC2785TP-E
Q303 8-729-900-80 TRANSISTOR BA1A4M-TP
To Next Page
