Sony SA-WMS5 - Control, Main, and Capacitor Components

– 16 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C207 1-136-170-00 FILM 0.27uF 5% 50V
C208 1-136-170-00 FILM 0.27uF 5% 50V
C210 1-136-177-00 FILM 1uF 5% 50V
C211 1-136-165-00 FILM 0.1uF 5% 50V
C212 1-126-965-11 ELECT 22uF 20% 50V
C213 1-126-965-11 ELECT 22uF 20% 50V
C214 1-126-965-11 ELECT 22uF 20% 50V
C215 1-126-964-11 ELECT 10uF 20% 50V
C216 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
* CN201 1-564-520-11 PLUG, CONNECTOR 5P
< IC >
IC201 8-759-634-50 IC M5218AL
IC202 8-759-634-50 IC M5218AL
IC203 8-759-634-50 IC M5218AL
< TRANSISTOR >
Q201 8-729-178-55 TRANSISTOR 2SC2785-E
< RESISTOR >
R201 1-249-427-11 CARBON 6.8K 5% 1/4W
R202 1-249-427-11 CARBON 6.8K 5% 1/4W
R203 1-247-887-00 CARBON 220K 5% 1/4W
R204 1-249-435-11 CARBON 33K 5% 1/4W
R205 1-249-417-11 CARBON 1K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
R207 1-247-883-00 CARBON 150K 5% 1/4W
R208 1-249-435-11 CARBON 33K 5% 1/4W
R209 1-249-427-11 CARBON 6.8K 5% 1/4W
R210 1-249-437-11 CARBON 47K 5% 1/4W
R211 1-249-432-11 CARBON 18K 5% 1/4W
R212 1-249-432-11 CARBON 18K 5% 1/4W
R213 1-249-417-11 CARBON 1K 5% 1/4W
R214 1-249-431-11 CARBON 15 5% 1/4W
R215 1-249-417-11 CARBON 1K 5% 1/4W
R216 1-249-427-11 CARBON 6.8K 5% 1/4W
R217 1-247-887-00 CARBON 220K 5% 1/4W
R218 1-247-887-00 CARBON 220K 5% 1/4W
R219 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV201 1-225-826-11 RES, VAR, CARBON 20K (LEVEL)
< SWITCH >
S201 1-771-632-11 SWITCH, ROTARY (MODE)
************************************************************
1-673-150-11 LED BOARD
**********
< CONNECTOR >
CN801 1-569-299-11 SOCKET, CONNECTOR (L TYRE) 5P
< LED >
D801 8-719-061-31 LED SML72420CTH8F (POWER ON/SAVE)
************************************************************
A-4419-286-A MAIN BOARD, COMPLETE
*********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
! C1 1-113-924-11 CERAMIC 0.0047uF 20% 250V
! C2 1-113-924-11 CERAMIC 0.0047uF 20% 250V
! C3 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C101 1-126-964-11 ELECT 10uF 20% 50V
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C103 1-136-176-00 FILM 0.82uF 5% 50V
C104 1-162-282-31 CERAMIC 100PF 10% 50V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
C106 1-162-292-31 CERAMIC 680PF 10% 50V
C107 1-162-288-31 CERAMIC 330PF 10% 50V
C108 1-162-282-31 CERAMIC 100PF 10% 50V
C109 1-126-964-11 ELECT 10uF 20% 50V
C110 1-126-964-11 ELECT 10uF 20% 50V
C301 1-162-282-31 CERAMIC 100PF 10% 50V
C302 1-126-963-11 ELECT 4.7uF 20% 50V
C303 1-162-219-31 CERAMIC 68PF 5% 50V
C304 1-162-289-31 CERAMIC 390PF 10% 50V
C305 1-162-194-31 CERAMIC 3.9PF 10% 50V
C306 1-126-934-11 ELECT 220uF 20% 10V
C307 1-128-560-11 ELECT 22uF 20% 100V
C308 1-128-560-11 ELECT 22uF 20% 100V
C309 1-130-483-00 MYLAR 0.01uF 5% 50V
C310 1-136-177-00 FILM 1uF 5% 50V
C311 1-130-495-00 MYLAR 0.1uF 5% 50V
C312 1-162-294-31 CERAMIC 0.001uF 10% 50V
C313 1-130-491-00 MYLAR 0.047uF 5% 50V
C314 1-104-665-11 ELECT 100uF 20% 10V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-104-664-11 ELECT 47uF 20% 25V
C317 1-162-209-31 CERAMIC 27PF 5% 50V
C501 1-127-891-11 ELECT 12000uF 20% 63V
C502 1-127-891-11 ELECT 12000uF 20% 63V
C503 1-136-165-00 FILM 0.1uF 5% 50V
C504 1-136-165-00 FILM 0.1uF 5% 50V
C505 1-126-941-11 ELECT 470uF 20% 25V
C506 1-126-941-11 ELECT 470uF 20% 25V
C507 1-104-664-11 ELECT 47uF 20% 25V
C508 1-104-664-11 ELECT 47uF 20% 25V
< CONNECTOR >
* CN101 1-564-521-11 PLUG, CONNECTOR 6P
* CN301 1-565-792-11 PIN, CONNECTOR 2P
* CN302 1-564-915-11 PIN, CONNECTOR 7P
CN501 1-564-321-00 PIN, CONNECTOR 2P
* CN502 1-564-687-11 PIN, CONNECTOR 3P
CN503 1-568-439-11 SOCKET, CONNECTOR 7P
* CN504 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
CONTROL LED MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
