SECTION 4
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUTO POWER
CONTROL
A-4419-290-A AUTO POWER BOARD, COMPLETE
****************************
< CAPACITOR >
C601 1-126-964-11 ELECT 10uF 20% 50V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-162-306-11 CERAMIC 0.01uF 20% 16V
C605 1-164-159-11 CERAMIC 0.1uF 50V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-126-956-91 ELECT 0.1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-126-916-11 ELECT 1000uF 20% 6.3V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-161-494-00 CERAMIC 0.022uF 25V
C612 1-126-942-61 ELECT 1000uF 20% 25V
C613 1-126-964-11 ELECT 10uF 20% 50V
C614 1-162-294-31 CERAMIC 0.001uF 10% 50V
C615 1-104-665-11 ELECT 100uF 20% 25V
C616 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN601 1-568-439-11 SOCKET, CONNECTOR 7P
* CN602 1-564-687-11 PIN, CONNECTOR 3P
* CN603 1-565-513-11 PIN, CONNECTOR 2P
CN604 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-200-82 DIODE 11ES2
D603 8-719-200-82 DIODE 11ES2
D604 8-719-200-82 DIODE 11ES2
D605 8-719-200-82 DIODE 11ES2
D606 8-719-985-85 DIODE HZS6A2L
< IC >
IC601 8-759-634-50 IC M5218AL
IC602 8-759-701-55 IC NJM2072D
< TRANSISTOR >
Q601 8-729-029-66 TRANSISTOR DTC114ESA
Q602 8-729-026-68 TRANSISTOR 2SD2525
Q603 8-729-422-57 TRANSISTOR UN4111
Q604 8-729-422-57 TRANSISTOR UN4111
Q605 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R601 1-247-887-00 CARBON 220K 5% 1/4W
R602 1-247-887-00 CARBON 220K 5% 1/4W
R603 1-249-431-11 CARBON 15K 5% 1/4W
R604 1-249-433-11 CARBON 22K 5% 1/4W
R605 1-249-435-11 CARBON 33K 5% 1/4W
R606 1-249-431-11 CARBON 15K 5% 1/4W
R607 1-249-433-11 CARBON 22K 5% 1/4W
R608 1-249-435-11 CARBON 33K 5% 1/4W
R611 1-249-431-11 CARBON 15K 5% 1/4W
R612 1-249-431-11 CARBON 15K 5% 1/4W
R613 1-249-415-11 CARBON 680 5% 1/4W
R614 1-249-417-11 CARBON 1K 5% 1/4W
R615 1-249-417-11 CARBON 1K 5% 1/4W
! R616 1-215-865-81 METAL OXIDE 220 5% 1W F
! R617 1-215-865-81 METAL OXIDE 220 5% 1W F
R618 1-249-429-11 CARBON 10K 5% 1/4W
R619 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
! RY601 1-755-276-11 RELAY, POWER
< SWITCH >
S701 1-570-707-31 SWITCH, SLIDE (POWER SAVE)
< TRANSFORMER >
! T601 1-433-731-11 TRANFOORMER, POWER (US, CND)
! T601 1-433-732-11 TRANFOORMER, POWER (EXCEPT US, CND)
************************************************************
1-673-146-11 CONTROL BOARD
**************
< CAPACITOR >
C201 1-104-664-11 ELECT 47uF 20% 25V
C202 1-104-664-11 ELECT 47uF 20% 25V
C203 1-136-176-00 FILM 0.82uF 5% 50V
C204 1-136-158-00 FILM 0.027uF 5% 50V
C205 1-136-163-00 FILM 0.068uF 5% 50V
C206 1-136-163-00 FILM 0.068uF 5% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model SP : Singapore model
