Sony SA-WMS5 - Power Switch, Accessories, and Hardware

– 18 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
Q403 8-749-010-25 IC MN2488-OPY-M
Q404 8-749-010-26 IC MP1620-OPY-M
< RESISTOR >
R401 1-249-421-11 CARBON 2.2K 5% 1/4W
R402 1-249-437-11 CARBON 47K 5% 1/4W
R403 1-249-414-11 CARBON 560 5% 1/4W
! R404 1-249-408-11 CARBON 180 5% 1/4W F
! R405 1-249-408-11 CARBON 180 5% 1/4W F
! R406 1-217-151-00 METAL 0.22 10% 2W F
! R407 1-217-151-00 METAL 0.22 10% 2W F
! R408 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
1-673-149-11 POWER SWITCH BOARD
********************
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
! S1 1-554-920-11 SWITCH, PUSH (AC POWER) (1 KEY)
(ON/STANDBY U)
************************************************************
MISCELLANEOUS
**************
! 56 1-769-744-11 CORD, POWER (AEP, UK, G, MY, SP)
! 56 1-783-531-11 CORD, POWER (US, CND)
! 57 1-569-008-21 ADAPTOR, CONVERSION 2P (SP)
! 58 1-770-019-21 ADAPTOR, CONVERSION PLUG 3P (UK)
105 1-694-516-11 TERMINAL, SPEAKER
SP1 1-529-296-11 SPEAKER (20cm)
SP100 1-529-292-11 SPEAKER (5cm)
! T501 1-433-726-11 TRANSFORMER, POWER (US, CND)
! T501 1-433-728-11 TRANSFORMER, POWER (EXCEPT US, CND)
! T601 1-433-731-11 TRANSFORMER, POWER (US, CND)
! T601 1-433-732-11 TRANSFORMER, POWER (EXCEPT US, CND)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-645-79 SCREW +P 3X6 TYPE2 SLIT
#2 7-685-146-29 SCREW +P 3X8 TYPE2 SLIT
#3 7-682-147-01 SCREW +P 3X6
#4 7-685-648-79 SCREW +P 3X12 TYPE2 NON-SLIT
#5 7-685-660-19 SCREW +BVTP 4X10 TYPE2 N-S
#6 7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
#7 7-624-200-11 NUT, PUSH 2
#8 7-685-163-01 SCREW +P 4X16 TYPE1
#9 7-685-116-01 SCREW +PTP 4X30 TYPE1
#10 7-685-662-79 SCREW +BVTP 4X14 TYPE2 N-S
************************************************************
POWER POWER SWITCH
SA-VE502/VE505/WMS5/SS-WMS5
Sony Corporation
Home A&V Products Company9-928-869-11
99D0587-1
Printed in Japan © 1999. 4
Published by Quality Assurance Dept.
(Shinagawa)
ACCESSORIES & PACKING MATERIALS
*******************************
1-769-329-21 CORD, CONNECTION (PIN-PIN)
1-790-503-11 CORD, SPEAKER (2.5m)
1-790-503-21 CORD, SPEAKER (10m) (VE505)
3-701-443-21 WASHER, 5 DIA.
3-866-761-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
3-866-761-21 MANUAL, INSTRUCTION (GERMAN, SPANISH,
DUTCH, SWEDISH, ITALIAN, PORTUGUESE,
POLISH, RUSSIAN, DANISH, FINNISH,
CHINESE) (EXCEPT US, CND)
4-219-450-01 SCREW (M5X16)
X-4951-476-1 STAY ASSY
X-4951-477-1 BASE ASSY
