Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
11
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
CND : Canadian model
SP : Singapore model
G : German model
MY : Malaysia model
A-4419-290-A AUTO POWER BOARD, COMPLETE
***************************
< CAPACITOR >
C601 1-126-964-11 ELECT 10uF 20% 50V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-162-306-11 CERAMIC 0.01uF 20% 16V
C605 1-164-159-11 CERAMIC 0.1uF 50V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-126-956-91 ELECT 0.1uF 20% 50V
C608 1-162-294-31 CERAMIC 0.001uF 10% 50V
C609 1-126-916-11 ELECT 1000uF 20% 6.3V
C610 1-126-964-11 ELECT 10uF 20% 50V
C611 1-161-494-00 CERAMIC 0.022uF 25V
C612 1-126-942-61 ELECT 1000uF 20% 25V
C613 1-126-964-11 ELECT 10uF 20% 50V
C614 1-162-294-31 CERAMIC 0.001uF 10% 50V
C615 1-104-665-11 ELECT 100uF 20% 25V
C616 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN601 1-568-439-11 SOCKET, CONNECTOR 7P
* CN602 1-564-687-11 PIN, CONNECTOR 3P
* CN603 1-565-513-11 PIN, CONNECTOR 2P
CN604 1-569-315-11 SOCKET, CONNECTOR 5P
* CN605 1-565-514-11 SOCKET, CONNECTOR 2P
< DIODE >
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-200-82 DIODE 11ES2
D603 8-719-200-82 DIODE 11ES2
D604 8-719-200-82 DIODE 11ES2
D605 8-719-200-82 DIODE 11ES2
D606 8-719-985-85 DIODE HZS6A2L
< IC >
IC601 8-759-634-50 IC M5218AL
IC602 8-759-701-55 IC NJM2072D
< TRANSISTOR >
Q601 8-729-029-66 TRANSISTOR DTC114ES
Q602 8-729-026-68 TRANSISTOR 2SD2525
Q603 8-729-422-57 TRANSISTOR DTA114ES
Q604 8-729-422-57 TRANSISTOR DTA114ES
Q605 8-729-422-57 TRANSISTOR DTA114ES
< RESISTOR >
R601 1-247-887-00 CARBON 220K 5% 1/4W
R602 1-247-887-00 CARBON 220K 5% 1/4W
R603 1-249-431-11 CARBON 15K 5% 1/4W
R604 1-249-433-11 CARBON 22K 5% 1/4W
R605 1-249-435-11 CARBON 33K 5% 1/4W
R606 1-249-431-11 CARBON 15K 5% 1/4W
R607 1-249-433-11 CARBON 22K 5% 1/4W
R608 1-249-435-11 CARBON 33K 5% 1/4W
R611 1-249-431-11 CARBON 15K 5% 1/4W
R612 1-249-431-11 CARBON 15K 5% 1/4W
R613 1-249-415-11 CARBON 680 5% 1/4W F
R614 1-249-417-11 CARBON 1K 5% 1/4W F
R615 1-249-417-11 CARBON 1K 5% 1/4W F
! R616 1-215-865-81 METAL OXIDE 220 5% 1W
! R617 1-215-865-81 METAL OXIDE 220 5% 1W
R618 1-249-429-11 CARBON 10K 5% 1/4W
R619 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY601 1-755-276-11 RELAY, POWER
< SWITCH >
S701 1-570-707-31 SWITCH, SLIDE (POWER SAVE)
************************************************************
1-674-329-11 CONTROL BOARD
**************
< CAPACITOR >
C201 1-104-664-11 ELECT 47uF 20% 25V
C202 1-104-664-11 ELECT 47uF 20% 25V
C203 1-136-173-00 FILM 0.47uF 5% 50V
C204 1-136-161-00 FILM 0.047uF 5% 50V
C205 1-136-163-00 FILM 0.068uF 5% 50V
AUTO POWER
CONTROL
To Next Page
