Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
14
1-673-147-11 POWER BOARD
************
< CAPACITOR >
C401 1-104-664-11 ELECT 47uF 20% 25V
C402 1-137-372-11 FILM 0.022uF 5% 50V
< CONNECTOR >
* CN401 1-770-318-11 PIN, CONNECTOR 7P
< TRANSISTOR >
Q401 8-729-119-76 TRANSISTOR 2SA1175-F
Q402 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q403 8-749-010-25 IC MN2488-OPY-M
Q404 8-749-010-26 IC MP1620-OPY-M
< RESISTOR >
R401 1-249-421-11 CARBON 2.2K 5% 1/4W F
R402 1-249-437-11 CARBON 47K 5% 1/4W
R403 1-249-414-11 CARBON 560 5% 1/4W F
! R404 1-249-408-11 CARBON 180 5% 1/4W F
! R405 1-249-408-11 CARBON 180 5% 1/4W F
! R406 1-217-151-00 METAL 0.22 10% 2W
! R407 1-217-151-00 METAL 0.22 10% 2W
! R408 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
1-674-330-11 POWER SWITCH BOARD
*******************
< SWITCH >
! S1 1-554-920-11 SWITCH, PUSH (AC POWER)(1 KEY)
(ON/STANDBY)
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
************************************************************
MISCELLANEOUS
**************
! 56 1-769-744-11 CORD, POWER (AEP,G,UK,MY,SP)
! 56 1-783-531-11 CORD, POWER (US,CND)
! 57 1-569-008-21 ADAPTOR, CONVERSION 2P (SP)
! 58 1-770-019-21 ADAPTOR, CONVERSION PLUG 3P (UK)
112 1-694-516-11 TERMINAL, SPEAKER
SP1 1-529-513-11 SPEAKER
SP101 1-529-291-11 SPEAKER (2.5cm)
SP102 1-529-290-11 SPEAKER (5cm)
SP103 1-529-290-11 SPEAKER (5cm)
! T501 1-433-726-11 TRANSFORMER, POWER (US,CND)
! T501 1-433-728-12 TRANSFORMER, POWER (AEP,G,UK,MY,SP)
! T601 1-433-731-11 TRANSFORMER, POWER (US,CND)
! T601 1-433-732-11 TRANSFORMER, POWER (AEP,G,UK,MY,SP)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-769-329-21 CORD, CONNECTION (PIN-PIN)
1-791-467-11 CORD, SPEAKER (10m)(VE705)
1-791-467-21 CORD, SPEAKER (2.5m)
3-867-384-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH)
3-867-384-21 MANUAL, INSTRUCTION
(GERMAN,SPANISH,DUTCH,SWEDISH,ITALIAN,
PORTUGUESE,POLISH,RUSSIAN,DANISH,
FINNISH,CHINESE)(AEP,G,UK,MY,SP)
4-222-421-01 SCREW (5 × 18), HEXAGON SOCKET
* 4-985-459-01 WRENCH, HEXAGON SHAFT
X-4951-969-1 FRAME ASSY, GRILLE
X-4952-023-1 STAND (V) ASSY
X-4952-024-1 STAND (H) ASSY (VE705)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-664-79 SCREW +P 4 × 20 TYPE1
#2 7-685-165-01 SCREW +PTP 4 × 25 TYPE1
#3 7-685-645-79 SCREW +P 3 × 6 TYPE2 SLIT
#4 7-682-147-01 SCREW +P 3 × 6
#5 7-685-146-29 SCREW +P 3 × 8 TYPE2 SLIT
#6 7-685-648-79 SCREW +P 3 × 12 TYPE2 NON-SLIT
#7 7-685-647-79 SCREW +P 3 × 10 TYPE2 NON-SLIT
#8 7-685-660-19 SCREW +BVTP 4 × 10 TYPE2 N-S
#9 7-624-200-01 NUT, PUSH 1.5
SA-VE702/VE705/WMS7/SS-MS7
Sony Corporation
Home Audio Company
9-928-978-11
99G1686-1
Printed in Japan ©1999.7
Published by Quality Assurance Dept.
POWER SWITCHPOWER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
