Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
13
< CONNECTOR >
* CN101 1-564-521-11 PLUG, CONNECTOR 6P
* CN301 1-565-792-11 PIN, CONNECTOR 2P
* CN302 1-564-242-00 PIN, CONNECTOR 5P
CN501 1-564-321-00 PIN, CONNECTOR 2P
* CN502 1-564-687-11 PIN, CONNECTOR 3P
CN503 1-568-439-11 SOCKET, CONNECTOR 7P
* CN504 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-991-33 DIODE 1SS133T-77
D105 8-719-991-33 DIODE 1SS133T-77
D106 8-719-991-33 DIODE 1SS133T-77
D107 8-719-991-33 DIODE 1SS133T-77
D108 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
D501 8-719-302-37 DIODE RBV-602
D503 8-719-200-82 DIODE 11ES2
D504 8-719-200-82 DIODE 11ES2
< FUSE >
! F1 1-532-501-31 FUSE (T0.8AL/250V)(AEP,G,UK,MY,SP)
! F1 1-533-296-11 FUSE,GLASS CYLINDRICAL(DIA.5)(2A/125V)
(US,CND)
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-634-50 IC M5218AL
IC301 8-749-011-16 IC STK350-230
IC302 8-759-634-50 IC M5218AL
IC303 8-759-111-68 IC uPC1237HA
IC501 8-759-604-40 IC M5F78M15L
IC502 8-759-604-46 IC M5F79M15L
< JACK >
J101 1-785-795-11 JACK, PIN 2P (LINE IN/OUT)
< RESISTOR >
R101 1-260-107-11 CARBON 4.7K 5% 1/2W
R102 1-260-107-11 CARBON 4.7K 5% 1/2W
R103 1-249-421-11 CARBON 2.2K 5% 1/4W F
R104 1-249-421-11 CARBON 2.2K 5% 1/4W F
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-429-11 CARBON 10K 5% 1/4W
R107 1-249-429-11 CARBON 10K 5% 1/4W
R108 1-249-429-11 CARBON 10K 5% 1/4W
R109 1-249-429-11 CARBON 10K 5% 1/4W
R110 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-249-429-11 CARBON 10K 5% 1/4W
R112 1-249-429-11 CARBON 10K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-249-417-11 CARBON 1K 5% 1/4W F
R115 1-247-887-00 CARBON 220K 5% 1/4W
R116 1-249-417-11 CARBON 1K 5% 1/4W F
R117 1-247-887-00 CARBON 220K 5% 1/4W
R118 1-249-421-11 CARBON 2.2K 5% 1/4W F
R119 1-249-427-11 CARBON 6.8K 5% 1/4W F
R120 1-249-421-11 CARBON 2.2K 5% 1/4W F
R121 1-249-421-11 CARBON 2.2K 5% 1/4W F
R122 1-249-417-11 CARBON 1K 5% 1/4W F
R123 1-249-441-11 CARBON 100K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R125 1-249-429-11 CARBON 10K 5% 1/4W
R126 1-249-437-11 CARBON 47K 5% 1/4W
R127 1-247-903-00 CARBON 1M 5% 1/4W
R301 1-249-419-11 CARBON 1.5K 5% 1/4W F
R302 1-249-438-11 CARBON 56K 5% 1/4W
R303 1-249-413-11 CARBON 470 5% 1/4W F
R304 1-249-438-11 CARBON 56K 5% 1/4W
R305 1-249-442-11 CARBON 510 5% 1/4W
! R308 1-247-688-11 CARBON 10 5% 1/4W F
! R309 1-247-688-11 CARBON 10 5% 1/4W F
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-437-11 CARBON 47K 5% 1/4W
R313 1-249-433-11 CARBON 22K 5% 1/4W
R314 1-249-429-11 CARBON 10K 5% 1/4W
R315 1-249-431-11 CARBON 15K 5% 1/4W
R316 1-249-415-11 CARBON 680 5% 1/4W F
R317 1-249-417-11 CARBON 1K 5% 1/4W F
! R318 1-217-151-00 METAL 0.22 10% 2W
R319 1-249-441-11 CARBON 100K 5% 1/4W
R320 1-216-505-51 METAL OXIDE 1.2K 5% 5W F
R321 1-247-838-00 CARBON 2K 5% 1/4W
R322 1-249-429-11 CARBON 10K 5% 1/4W
R323 1-249-420-11 CARBON 1.8K 5% 1/4W F
R324 1-249-421-11 CARBON 2.2K 5% 1/4W F
R325 1-249-425-11 CARBON 4.7K 5% 1/4W F
R326 1-247-860-11 CARBON 16K 5% 1/4W
R327 1-249-422-11 CARBON 2.7K 5% 1/4W F
R328 1-249-441-11 CARBON 100K 5% 1/4W
R330 1-249-439-11 CARBON 68K 5% 1/4W
R331 1-249-433-11 CARBON 22K 5% 1/4W
R334 1-249-436-11 CARBON 39K 5% 1/4W
R335 1-249-432-11 CARBON 18K 5% 1/4W
! R501 1-249-381-11 CARBON 1 5% 1/4W F
! R502 1-249-381-11 CARBON 1 5% 1/4W F
< RELAY >
RY301 1-515-920-11 RELAY (24V)
< TERMINAL >
TM101 1-537-737-11 TERMINAL BOARD (SPEAKER)
************************************************************
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
