(2) AMPLIFIER SECTION
(SA-WMS7)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51 1-673-147-11 POWER BOARD
52 A-4426-644-A MAIN BOARD, COMPLETE
53 4-222-939-11 PANEL, REAR (US,CND)
53 4-222-939-21 PANEL, REAR (AEP,G,UK,MY,SP)
* 54 3-703-244-00 BUSHING (2104), CORD
55 3-710-901-11 SCREW, TAPPING
! 56 1-769-744-11 CORD, POWER (AEP,G,UK,MY,SP)
! 56 1-783-531-11 CORD, POWER (US,CND)
! 57 1-569-008-21 ADAPTOR, CONVERSION 2P (SP)
! 58 1-770-019-21 ADAPTOR, CONVERSION PLUG 3P (UK)
59 A-4419-290-A AUTO POWER BOARD, COMPLETE
! T501 1-433-726-11 TRANSFORMER, POWER (US,CND)
! T501 1-433-728-12 TRANSFORMER, POWER (AEP,G,UK,MY,SP)
! T601 1-433-731-11 TRANSFORMER, POWER (US,CND)
! T601 1-433-732-11 TRANSFORMER, POWER (AEP,G,UK,MY,SP)
51
52
54
53
59
not supplied
not supplied
#7
#7
#7
#7
#7
T501
#7
#8
#8
#8
#8
not supplied
T601
not supplied
56
57
58
UK MODEL SP MODEL
US,CND MODEL
AEP,G,MY,SP,
UK MODEL
56
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
