SDM-E96A/D
Ref. No. SONY Part No. SONY name
X21099931 BEZEL ASSY (E96D)
X21480881 BEZEL ASSY (E96A)
178959421 Mounted PWB, H (Key board for E96A)
178959411 Mounted PWB, H (Key board for E96D)
180216511 Panel: M190EG04V5 (AUO)
180216411 Panel: HSD190ME13-A10 (HANNSTAR)
178959031 Mounted PWB, A (Main board) (E96D for HannStar)
178959131 Mounted PWB, A (Main board) (E96A for HannStar)
178959041 Mounted PWB, A (Main board) (E96D for AUO)
178959141 Mounted PWB, A (Main board) (E96A for AUO)
178959311 Mounted PWB, G (Power board) (for AUO)
178958911 Mounted PWB, G (Power board) (for HANNSTAR)
6 191002852 Connector Assy (Panel Link Cable)
7 X21099951 HINGE ASSY
8 268576501
Rubber, Front Foot
(Only 1 piece)
(Only 1 piece)
9 268576601 STAND
268576901 SHIELD, REAR (E96D)
268576911 SHIELD, REAR (E96A)
11 268576001 CABINET, REAR
12 268576101 MULTI BUTTON
13 268576201 FRONT POWER BUTTON
14 269348001
HEXAGON SCREW
182984911 POWER CORD, BLACK (AEP)
182984811 POWER CORD, BLACK (U/C)
183086221 POWER CORD, BLACK (WB)
183344411 POWER CORD, BLACK (CH)
16 182985511 DVI CABLE
17 182987611 D-SUB CABLE
268147621 QUICK SETUP GUIDE (AEP)
268147611 QUICK SETUP GUIDE (U/C,WB)
19 268595601 CD-ROM
1
2
3
5
10
4
18
15
ACCESSORIES & PACKING MATERIALS
※Please refer to the following URL of TV QA web page to see the latest service parts list.
http://www.tvdg.sony.co.jp/cs/sdm-pn/index.html
