Sony SDM-E76A - Specifications

SPECIFICATIONS
1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Active Display Area : 17 inch - SDM-E76A/D
: 19 inch - SDM-E96A/D
Pixel Pitch : 0.264 (H) x 0.264 (V) -SDM-E76A/D
: 0.294 (H) x 0.294 (V) -SDM-E96A/D
Size : 358.5(W) x 296.5(H) x 17.5(D)
- SDM-E76A/D
: 396(W) x 324(H) x 17.5(D)
- SDM-E96A/D
Color Depth : 16.2M colors - SDM-E76A/D
: 16.2M colors - SDM-E96A/D
Electrical Interface : LVDS
Surface Treatment : Anti Glare, Hard-coating (3H)
Operating Mode : Normally White
Backlight Unit : Top/Bottom edge side 4-CCFL
(Cold Cathode Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio > 10
SDM-E76A/D
Left : 70°(Typ) Right : 70°(Typ)
Top : 70°(Typ) Bottom : 60°(Typ)
SDM-E96A/D
Left : -65° min., -70°(Typ) Right : +65° min., +70°(Typ)
Top :+70° min., +75°(Typ) Bottom : -55°min., -60°(Typ)
2-2. Luminance :
300(Typ) - SDM-E76A/D
300(Typ) - SDM-E96A/D
2-3. Contrast Ratio :
500:1 (Typ) - SDM-E76A/D
700:1 (Typ) - SDM-E96A/D
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
Type : Separate Sync, Composite Sync,
SOG (Sync On Green), Digital
3-2. Video Input Signal
1) Type: R, G, B Analog
2) Voltage Level: 0~0.71 V
a) Color 0, 0: 0 Vp-p
b) Color 7, 0: 0.467 Vp-p
c) Color 15, 0: 0.714 Vp-p
3) Input Impedance : 75Ω
3-3. Operating Frequency
Analog Digital
Horizontal: 28 ~ 80kHz 28 ~ 64kHz
Vertical: 56 ~ 75Hz 60Hz
Dot Clock:
< 135MHz < 108MHz
4. Max. Resolution
Analog : 1280 x 1024 / 75Hz
Digital : 1280 x 1024 / 60Hz
5. POWER SUPPLY
5-1. Power: AC 100~240V, 50/60Hz,
5-2. Power Consumption
SDM-E76A/D
Normal operation < 38W
Active off (deep sleep) < 1W
Power off < 1W
SDM-E96A/D
Normal operation < 44W
Active off (deep sleep) < 1W
Power off < 1W
6. ENVIRONMENT
6-1. Operating Temperature:
5°C~35°C (41°F~95°F)
6-2. Relative Humidity:
10%~80% (Non-condensing)
7. DIMENSIONS
SDM-E76A/D
Width: 382 mm (15.1'')
Depth: 193.2 mm (7.6'')
Height: 403.2 mm (15.9'')
SDM-E96A/D
Width: 420 mm (16.6'')
Depth: 193.2 mm (7.6'')
Height: 433.1 mm (17.1”)
8. WEIGHT
SDM-E76A/D
Net. Weight: 4.5 kg (9.9 lbs)
Gross Weight: 5.6 kg (12.31 lbs)
SDM-E96A/D
Net. Weight : 5.5kg (12.1 lbs)
Gross Weight: 7.2kg (15.9 lbs)
