SDM-HS94/HS94P (E)
EXPLODED VIEW PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
X-2022-696-1 BEZEL ASSY (HS94, Black)
X-2022-718-1
BEZEL ASSY (HS94, Blue)
X-2022-698-1 BEZEL ASSY (HS94P, Black)
X-2022-719-1 BEZEL ASSY (HS94P, Silver)
1-805-347-21 LCD PANEL (Fujitsu) (HS94)
1-805-644-11 LCD PANEL (AU) (HS94)
1-805-751-11 LCD PANEL (AU) (HS94P)
X-2022-697-1 BACK CABINET ASSY (HS94, HS94P, Black)
X-2022-721-1 BACK CABINET ASSY (HS94, Blue)
X-4041-491-1 CENTER CABINET ASSY (HS94)
X-2022-700-1 CENTER CABINET ASSY (HS94P)
4-094-676-01 HINGE COVER (HS94)
4-094-676-31 HINGE COVER (HS94P)
X-4041-492-1 STAND ASSY (HS94)
X-2022-701-1 STAND ASSY (HS94P)
A-1066-954-A H MOUNT (HS94/HS94P)
4-094-671-31 BOTTOM VENT COVER (HS94, HS94P, Black)
4-094-671-21 BOTTOM VENT COVER (HS94, Blue)
1-900-275-71 CONNECTOR ASSY (HS94/HS94P)
A-1070-059-A G MOUNT (for Fujitsu) (HS94)
A-1070-062-A G MOUNT (for AU) (HS94)
A-1070-062-A G MOUNT (for AU) (HS94P)
A-1070-060-A A MOUNT (for Fujitsu) (HS94)
A-1070-063-A
A MOUNT (for AU) (HS94)
A-1070-077-A
A MOUNT (HS94P)
2-149-425-01 REAR COVER (HS94, Black)
2-149-425-31 REAR COVER (HS94, Blue)
2-149-425-11 REAR COVER (HS94P, Black)
2-149-425-41 REAR COVER (HS94P, Silver)
1-827-110-21 D-SUB CABLE (HS94)
1-827-757-11 D-SUB CABLE (HS94P)
1-829-852-11
DVI CABLE (HS94)
1-827-758-11 DVI CABLE (HS94P)
1-827-120-21 POWER-SUPPLY CORD SET (AEP) (HS94)
1-827-122-21 POWER-SUPPLY CORD SET (CH) (HS94)
1-827-118-11 POWER-SUPPLY CORD SET (U/C) (HS94P)
1-827-120-11 POWER-SUPPLY CORD SET (AEP) (HS94P)
1-827-122-11 POWER-SUPPLY CORD SET (CH) (HS94P)
2-103-460-01 QUICK SETUP GUIDE (AEP) (HS94/HS94P)
4-094-401-01 PROTECTION BAG (HS94/HS94P)
2-149-428-01 CUSHION (HS94/HS94P)
2-148-719-01 INDIVIDUAL CARTON (HS94)
2-148-721-01 INDIVIDUAL CARTON (HS94P)
2-148-303-01 CD-ROM (HS94/HS94P)
2-103-460-11 QUICK SETUP GUIDE (U/C, CH) (HS94/HS94P)
Description
Part No.
Ref. No.
ACCESSORIES & PACKING MATERIALS
9-878-265-01
English
2004IR02-1
Made in Japan
© 2004.9
Sony EMCS Corporation
Ichinomiya Tec
