— 70 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
R268 1-247-807-31 CARBON 100 5% 1/4W
R269 1-247-807-31 CARBON 100 5% 1/4W
R270 1-247-807-31 CARBON 100 5% 1/4W
R271 1-247-807-31 CARBON 100 5% 1/4W
R272 1-260-103-11 CARBON 2.2K 5% 1/2W
R273 1-249-425-11 CARBON 4.7K 5% 1/4W F
R274 1-249-425-11 CARBON 4.7K 5% 1/4W F
R275 1-249-413-11 CARBON 470 5% 1/4W F
R276 1-260-070-11 CARBON 3.3 5% 1/2W
R277 1-249-429-11 CARBON 10K 5% 1/4W
R278 1-249-429-11 CARBON 10K 5% 1/4W
R279 1-249-429-11 CARBON 10K 5% 1/4W
R280 1-260-070-11 CARBON 3.3 5% 1/2W
< SWITCH >
S2 1-475-074-11 ENCODER, ROTARY (WITH SW)
(MENU, PUSH ENTER)
S3 1-475-075-11 ENCODER, ROTARY (+/-)
S251 1-554-303-21 SWITCH, TACTILE (AC-3 RF)
S252 1-554-303-21 SWITCH, TACTILE (DIGITAL 1)
S253 1-554-303-21 SWITCH, TACTILE (DIGITAL 2)
S254 1-554-303-21 SWITCH, TACTILE (DIGITAL 3)
S255 1-554-303-21 SWITCH, TACTILE (BASS BOOST)
S256 1-554-303-21 SWITCH, TACTILE (DOLBY SURR)
S257 1-554-303-21 SWITCH, TACTILE (MODE)
S258 1-554-303-21 SWITCH, TACTILE (OFF)
S259 1-554-303-21 SWITCH, TACTILE (DIGITAL 4 COAXIAL)
S260 1-554-303-21 SWITCH, TACTILE (SET UP)
S261 1-554-303-21 SWITCH, TACTILE (BYPASS)
**************************************************************
* A-4392-301-A MAIN BOARD, COMPLETE
********************
7-682-548-09 SCREW (3X8)
4-989-736-01 SPACER
< CAPACITOR >
C151 1-124-557-11 ELECT 1000uF 20% 25V
C152 1-124-557-11 ELECT 1000uF 20% 25V
C153 1-124-563-11 ELECT 2200uF 20% 25V
C154 1-124-563-11 ELECT 2200uF 20% 25V
C155 1-124-563-11 ELECT 2200uF 20% 25V
C201 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C202 1-126-049-11 ELECT 22uF 20% 50V
C203 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C204 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C205 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C206 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C207 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C208 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C209 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C254 1-126-964-11 ELECT 10uF 20% 50V
C255 1-126-964-11 ELECT 10uF 20% 50V
C257 1-164-159-11 CERAMIC 0.1uF 50V
C258 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN107 1-564-523-11 PLUG, CONNECTOR 8P
* CN206 1-568-867-11 SOCKET, CONNECTOR 25P
< DIODE >
D251 8-719-987-63 DIODE 1N4148M
D252 8-719-987-63 DIODE 1N4148M
D253 8-719-987-63 DIODE 1N4148M
D254 8-719-933-39 DIODE HZS6C1L
D255 8-719-024-99 DIODE 11ES2-NTA2B
D257 8-719-987-63 DIODE 1N4148M
D258 8-719-987-63 DIODE 1N4148M
< FLUORESCENT INDICATOR >
FL251 1-517-645-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC251 8-759-999-53 IC MSC1164GS-K
IC252 8-759-075-35 IC TD62C950RF
IC253 8-759-962-08 IC BA6208
IC254 8-759-916-48 IC SN74HC151AN
IC255 8-759-916-48 IC SN74HC151AN
IC256 8-759-373-49 IC NJL54H400
< TRANSISTOR >
Q251 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R251 1-249-429-11 CARBON 10K 5% 1/4W
R252 1-249-429-11 CARBON 10K 5% 1/4W
R253 1-249-429-11 CARBON 10K 5% 1/4W
R254 1-249-429-11 CARBON 10K 5% 1/4W
R255 1-249-429-11 CARBON 10K 5% 1/4W
R256 1-249-429-11 CARBON 10K 5% 1/4W
R257 1-249-429-11 CARBON 10K 5% 1/4W
R258 1-249-429-11 CARBON 10K 5% 1/4W
R259 1-249-429-11 CARBON 10K 5% 1/4W
R260 1-249-429-11 CARBON 10K 5% 1/4W
R261 1-249-429-11 CARBON 10K 5% 1/4W
R262 1-249-429-11 CARBON 10K 5% 1/4W
R263 1-249-429-11 CARBON 10K 5% 1/4W
R264 1-249-429-11 CARBON 10K 5% 1/4W
R265 1-249-429-11 CARBON 10K 5% 1/4W
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-429-11 CARBON 10K 5% 1/4W
MAIN
