— 69 —
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
CH : Chinese model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
Les composants identifiés par une
marque ! sont critiques pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 7
ELECTRICAL PARTS LIST
Note:
C115 1-136-165-00 FILM 0.1uF 5% 50V
C116 1-128-555-11 ELECT 470uF 20% 63V
C123 1-162-294-31 CERAMIC 0.001uF 10% 50V
C124 1-164-159-11 CERAMIC 0.1uF 50V
C125 1-164-159-11 CERAMIC 0.1uF 50V
C126 1-164-159-11 CERAMIC 0.1uF 50V
C127 1-164-159-11 CERAMIC 0.1uF 50V
C128 1-162-294-31 CERAMIC 0.001uF 10% 50V
C129 1-162-294-31 CERAMIC 0.001uF 10% 50V
C130 1-162-294-31 CERAMIC 0.001uF 10% 50V
C131 1-164-159-11 CERAMIC 0.1uF 50V
C132 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN305 1-564-242-00 PIN, CONNECTOR 5P
* CN306 1-564-243-11 PIN, CONNECTOR 6P
< DIODE >
D101 8-719-302-37 DIODE RBV-602
D112 8-719-302-37 DIODE RBV-602
D113 8-719-987-63 DIODE 1N4148M
D114 8-719-987-63 DIODE 1N4148M
D115 8-719-024-99 DIODE 11ES2-NTA2B
D116 8-719-024-99 DIODE 11ES2-NTA2B
D117 8-719-024-99 DIODE 11ES2-NTA2B
D118 8-719-024-99 DIODE 11ES2-NTA2B
< EARTH >
* E1 1-537-738-21 TERMINAL, EARTH
* E2 1-537-738-21 TERMINAL, EARTH
**************************************************************
* A-4392-303-A DISPLAY BOARD, COMPLETE
***********************
* 4-921-941-71 CUSHION (FL)
* 4-987-862-01 HOLDER (FL TUBE)
< CAPACITOR >
C251 1-126-964-11 ELECT 10uF 20% 50V
C252 1-164-159-11 CERAMIC 0.1uF 50V
C253 1-164-159-11 CERAMIC 0.1uF 50V
* 1-664-277-11 AC1 BOARD
**********
< CAPACITOR >
! C1 1-115-383-11 CERAMIC 0.001uF 10% 125V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
* CN2 1-565-792-11 PIN, CONNECTOR 2P
CN3 1-564-321-00 PIN, CONNECTOR 2P (US,CND,AEP)
* CN3 1-564-687-11 PIN, CONNECTOR 3P (E,MY,SP,CH)
< FUSE >
! F1 1-532-389-51 FUSE, TIME-LAG (500mA/250V)(AEP,E,MY,SP,CH)
! F1 1-576-102-11 FUSE (1.5A/250V)(US,CND)
! F2 1-532-501-51 FUSE, TIME-LAG (800mA/250V)(E,MY,SP,CH)
< FUSE HOLDER >
FH1 1-533-293-11 FUSE HOLDER
FH2 1-533-293-11 FUSE HOLDER (E,MY,SP,CH)
FH3 1-533-293-11 FUSE HOLDER
FH4 1-533-293-11 FUSE HOLDER (E,MY,SP,CH)
< COIL >
! L1 1-421-915-11 COIL, LINE FILTER
< SWITCH >
! S4 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR)(E,MY,SP,CH)
**************************************************************
* 1-664-278-11 AC2 BOARD
**********
< BUS BAR >
BB101 1-560-242-11 BUS BAR
< CAPACITOR >
C102 1-126-057-11 ELECT 2200uF 20% 50V
C103 1-126-057-11 ELECT 2200uF 20% 50V
C109 1-117-783-11 ELECT 13000uF 20% 16V
C110 1-126-013-11 ELECT 1000uF 20% 16V
AC1 AC2 DISPLAY
To Next Page
