4
GB
Unpacking
• Speaker (1) (with the speaker grille attached)
The speaker grille must be removed before painting
the speaker enclosure.
• Power cord (1)
The shape of the AC power plug varies depending
on region of your residency.
• Power cascade cable (Euro type terminal block
(Pitch 5.08 mm, 4-pin, Black/Green)) (1)
• Ethernet cable for audio signal cascade (RJ-45) (1)
• 3-pin Euro type terminal block header (1)
• Speaker bracket (no slant) (2)
Speaker bracket (10-degree slant) (2)
• Speaker joint bracket (no slant) (1)
Speaker joint bracket (10-degree slant) (1)
• Wall mounting bracket (1)
• Metal joint fitting for wall mounting brackets (1)
• Detachment stopper (2)
• Metal joint fitting for attaching a safety wire (2)
• Cable clamp (2)
• Spacer pad A (2)
• Spacer pad B (1)
• 4×10 screw with washer (9)
• Shoulder screw (2)
• Operating Instructions (this manual) (1)
• Reference Guide (1)
• Warranty card (1)
