Sony SLS-1A - Additional Information; Specifications

22
GB
Additional Information
Specifications
System
Module (1 module) (2 modules) (3 modules) (4 modules) (5 modules) (6 modules)
Frequency Range
* Depends on the
frequency response
measured in an
anechoic chamber.
80 Hz - 20 kHz
Horizontal Dispersion
* 1 - 4 kHz average, -6 dB
For vertical installation
(Vertical Dispersion for
horizontal installation)
200 degrees
Vertical Opening
Angles
* For vertical installation
(Horizontal Opening
Angles for horizontal
installation)
Software
Adjustable:
Max
40 degrees
Software
Adjustable:
Max
50 degrees
Software
Adjustable:
Max
60 degrees
Software
Adjustable:
Max
70 degrees
Software
Adjustable:
Max
80 degrees
Software
Adjustable:
Max
90 degrees
Vertical Beam Steering
Angles
* For vertical installation
(Horizontal Beam
Steering Angles for
horizontal installation)
20 degrees 20 degrees 30 degrees 30 degrees 40 degrees 40 degrees
Maximum Sound
Pressure Level (1 m)
* The value for Module
1 is calculated based
on the actual value
measured without
beam control in an
anechoic chamber.
The values for Modules
2 to 6 are calculated
based on the Module
1 value.
105 dB
(peak 112 dB)
111 dB
(peak 118 dB)
115 dB
(peak 122 dB)
117 dB
(peak 124 dB)
119 dB
(peak 126 dB)
121 dB
(peak 128 dB)
Peak Sound Pressure
Level (30 m)
* 15 dB signal loss per
30 m is assumed.
97 dB 103 dB 107 dB 109 dB 111 dB 113 dB
Typical Usable Throw
Distance
* Typical Maximum
Usable Throw Distance
includes considerations
for reverberation and
speech intelligibility.
4 m 8 m 12 m 16 m 20 m 25 m
