SIGNAL indicator
Lit (green):
Indicates that input signals are at an appropriate
level.
Lit (yellow):
Indicates that Dynamic Range Compression (DRC) is
active.
Lit (red):
Indicates that input signals are clipped. Decrease the
signal level.
Unlit:
Indicates that the speaker is receiving no input
signals.
RESET button
Provided for restoring the default state of the speaker.
Use a long thin object, such as a hair pin, to push the
button all the way in.
Dimensions
Width: Approx. 384 mm (15
1
/8 in)
Height: Approx. 92 mm (3
5
/8 in)
Depth: Approx. 110 mm (4
3
/8 in)
(with the speaker bracket unattached)
Depth: Approx. 114 mm (4
1
/2 in)
(with the speaker bracket (no slant)
attached)
Depth: Approx. 122 mm (4
7
/8 in)
(with the speaker bracket (10-degree slant)
attached)
