Sony SLT-A58K - PD-1017 BOARD

SLT-A58K/A58M/A58Y_L3
6-26
LCD-2002
FLEXIBLE
LN7402
(PAGE 6-30)
Note: C6407 is not supplied, but this is
included in PD-1017 COMPLETE BOARD.
Note: LCD901 is not included in PD-1017 COMPLETE BOARD.
12345 6 7 8 9
A
B
C
D
E
F
A
B
C
D
E
F
08
PD-1017 BOARD
LCD
XX MARK: NO MOUNT
L6401
10uH
CL6404
R6401
XX
CL6403
C6405
1u
C6407 1u
R6405 XX
R6404 XX
C6408
2.2u
CL6402
C6414 1u C6416 1u
C6401
1u
C6403
1u
C6406 1u
CL6405
C6404
1u
R6406
XX
R6403 XX
C6415
1u
C6409 1u
C6402
1u
C6412
1u
C6411
1u
C6413 1u
C6410
1u
C6417
XX
R6402 XX
CL6401
CN6401
51P
1
GND
2
GRB
3
CS
4
SDIN
5
SCLK
6
VDDIO
7
VDD_18V
8
DCLK
9
VS
10
HS
11
DY7
12
DY6
13
DY5
14
DY4
15
DY3
16
DY2
17
DY1
18
DY0
19
DC7
20
DC6
21
DC5
22
DC4
23
DC3
24
DC2
25
DC1
26
DC0
27
VCOMH
28
VCOMH
29
VCOML
30
VCOML
31
VDD
32
VDD
33
GND
34
VINT2
35
V9
36
V10
37
VINT1
38
VINT1
39
AGND
40
V1
41
V2
42
V3
43
V4
44
V5
45
V6
46
VGH
47
V7
48
V8
49
VGL
50
LED+
51
LED-
CN6402
39P
1
RESET
2
XCS
3
SI
4
REG_GND
5
SCK
6
XHD
7
XVD
8
REG_GND
9
DCLK
10
REG_GND
11
D7
12
REG_GND
13
D6
14
REG_GND
15
D5
16
REG_GND
17
D4
18
REG_GND
19
D3
20
REG_GND
21
D2
22
REG_GND
23
D1
24
REG_GND
25
D0
26
REG_GND
27
D_3.1V
28
BL_A
29
BL_K
30
REG_GND
31
DY7
32
DY6
33
DY5
34
DY4
35
DY3
36
DY2
37
DY1
38
DY0
39
REG_GND
LCD901
(LCD MODULE)
2.7 INCH
COLOR LCD
LCD BACKLIGHT
