Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
13
SRF-M37
R113 1-216-845-11 METAL CHIP 100K 5% 1/16W
R114 1-216-821-11 METAL CHIP 1K 5% 1/16W
R115 1-216-821-11 METAL CHIP 1K 5% 1/16W
R117 1-216-821-11 METAL CHIP 1K 5% 1/16W
R118 1-216-821-11 METAL CHIP 1K 5% 1/16W
R119 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R120 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R121 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R122 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R123 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R124 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R125 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R126 1-216-845-11 METAL CHIP 100K 5% 1/16W
R127 1-216-857-11 METAL CHIP 1M 5% 1/16W
R128 1-216-833-11 METAL CHIP 10K 5% 1/16W
R129 1-216-845-11 METAL CHIP 100K 5% 1/16W
R130 1-216-853-11 METAL CHIP 470K 5% 1/16W
R131 1-216-833-11 METAL CHIP 10K 5% 1/16W
R132 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R133 1-216-833-11 METAL CHIP 10K 5% 1/16W
R134 1-216-845-11 METAL CHIP 100K 5% 1/16W
R135 1-216-821-11 METAL CHIP 1K 5% 1/16W
R136 1-216-841-11 METAL CHIP 47K 5% 1/16W
R137 1-216-845-11 METAL CHIP 100K 5% 1/16W
R138 1-216-845-11 METAL CHIP 100K 5% 1/16W
R139 1-216-797-11 METAL CHIP 10 5% 1/16W
R140 1-216-845-11 METAL CHIP 100K 5% 1/16W
R143 1-216-845-11 METAL CHIP 100K 5% 1/16W
R144 1-216-845-11 METAL CHIP 100K 5% 1/16W
R146 1-216-845-11 METAL CHIP 100K 5% 1/16W
< SWITCH >
S101 1-771-722-11 SWITCH, SLIDE (HOLD)
< TRANFORMER >
T101 1-439-578-11 TRANSFORMER, DC/DC CONVERTER
< VIBRATOR >
X101 1-767-388-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
* A-3347-447-A MAIN BOARD, COMPLETE
*********************
3-247-147-01 HOLDER (ANT)
3-247-148-01 HOLDER (H/P)
< FILTER >
BPF1 1-236-711-21 FILTER, BAND PASS
< CAPACITOR >
C1 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C2 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C4 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C6 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C7 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C8 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C9 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C17 1-162-913-11 CERAMIC CHIP 8PF 0.50PF 50V
C18 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C19 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C20 1-115-156-11 CERAMIC CHIP 1uF 10V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C24 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
C25 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C27 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C29 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C30 1-124-259-11 ELECT 4.7uF 20.00% 16V
C31 1-126-518-11 ELECT 470uF 20.00% 4V
C32 1-126-518-11 ELECT 470uF 20.00% 4V
C33 1-115-156-11 CERAMIC CHIP 1uF 10V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C37 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C38 1-115-156-11 CERAMIC CHIP 1uF 10V
C39 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C40 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C41 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C42 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C43 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C44 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C45 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C46 1-115-156-11 CERAMIC CHIP 1uF 10V
C47 1-115-156-11 CERAMIC CHIP 1uF 10V
C48 1-126-157-11 ELECT 10uF 20% 16V
C49 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C50 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C51 1-115-156-11 CERAMIC CHIP 1uF 10V
C52 1-115-156-11 CERAMIC CHIP 1uF 10V
C53 1-126-518-11 ELECT 470uF 20.00% 4V
C54 1-124-584-00 ELECT 100uF 20% 10V
C55 1-124-584-00 ELECT 100uF 20% 10V
C60 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< FILTER >
CF1 1-795-846-21 FILTER, CERAMIC
CF2 1-795-323-11 FILTER, CERAMIC
CF3 1-795-845-21 DISCRIMINATOR, CERAMIC
< TRIMMER >
CT1 1-141-601-11 CAP, ADJ
CT2 1-141-601-11 CAP, ADJ
< DIODE >
D1 8-719-987-50 DIODE HVU-300A-TRU
D2 8-719-987-50 DIODE HVU-300A-TRU
D3 8-719-987-50 DIODE HVU-300A-TRU
D4 6-500-187-01 DIODE KV1610STL2
D6 8-719-062-51 DIODE 1PS226-115
D7 8-719-062-51 DIODE 1PS226-115
KEY MAIN
