SRF-M37
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. Cabinet (Front) Assy
CABINET (FRONT) ASSY
KEY BOARD ASSY
MAIN BOARD ASSY
SET
• This set can be disassembled in the order shown below.
2 four tapping screws
(B 1.7
× 6)
3 cabinet (front) assy
1 Open the battery case lid.
