Sony SRF-M37 - Page 4

4
SRF-M37
2-3. MAIN Board Assy
2-2. KEY Board Assy
5 battery terminal (+)
4 battery terminal (-)
6 KEY board assy
3 two hooks
1 Remove the soldering from two points.
2 Remove the soldering
from the eleven points.
4 MAIN board ass
y
2 Remove the soldering
from the eleven points.
1 two tapping screws
(B 1.7 × 6)
3 two wire
